5 band Backpack GSM 3G 4G 5G IMSI Catcher system 200 meters

5 band Backpack GSM 3G 4G 5G IMSI Catcher system 200 meters

Product Description:

Portable code detection locator is a product specifically designed for the security industry. Used in mobile scenarios to collect mobile terminal feature information within the wireless signal coverage area of the code detection device. The terminal information is displayed or data is transmitted back to the code detection warning and control platform through mobile app software, with functions such as setting target alarms and positioning tracking.

IMSI Catcher Mobile APP software:
device management           Code detection information
Code detection restart        Code detection list
Code detection scanning    Code detection black/white list
Code detection power          Collision analysis
Mode switching                    Adjoint analysis
Start/End                              target location

IMSI Catcher Specifications
Product type  Backpack IMIS Catcher System (5 channels)
Working system
TDD-LTE: B34, B38, B39, B40, B41
FDD-LTE: B1, B3
GSM: B5, B8
Supports 5G mobile phone registration on NSA network.
(Backpack style supports up to 5 channels, more channels need to choose the portable style or vehicle mounted style)
Adjustable power range (W)     10W

Synchronization method  Air synchronization, GPS synchronization
Data retrieval   Local WIFI or wireless return
Power supply mode (V)  Internal battery or external DC-12V
Working temperature (℃)   -30 ° C~+55 ° C
Working humidity ()   10 ~90
Dimensions (L * W * H mm)   330 * 225 * 75mm
Weight (Kg)  ≤ 6.9Kg
Power consumption (W) <150W, with built-in fan for heat dissipation
External antenna Directional (built-in)
Battery endurance 2.0 hours
Protection level  IP32
