Application Area:

High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services,

Oil station, gas filled station, oil field, oil depot, etc

This High power waterproof Blaster GPS WIFI All Cell phone Frequency Jammer ,the total outputs 500W and reach a wide range up to 600m with jamming radius depending on the signal strength in the given area.

Good cooling system with cooling fan inside but also use External Omni-directional antennas, all the TX frequency covered down link only, so that this cell phone jammer can always stay in good working condition.

Specification:

• Affected Frequency Ranges:

CH-CDMA/GSM: 851-960MHz
CH-DCS: 1805-1880MHz
CH-PCS: 1920-1990MHz
CH-3G: 2110-2170MHz
CH-4G LTE: (US.725-770MHz) or (Europe:790-826MHz)
CH-4GWIMAX:(US. 2345-2400MHz) or (Europe: 2620-2690MHz)
CH-GPS: 1570-1580MHz
CH-WiFi2.4g: 2400-2500MHz

CH​-WiFi5.8g:5200-5800MHz

• Total output power:500W
• Jamming range: up to 100-600m, the jamming radius still depends on the strength signal in given area
• External double channel directional panel antennas all the TX frequency covered down link only
• Power supply: 50 to 60Hz, 100 to 240V AC
• With AC adapter (AC100-240V-DC27V),
• Dimension: 420×480×230 mm

Accessories

• High Power Cell Phone Signal Jammer
• Antennas
• Power cable

Advantages and Features:

• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
• Heat sink designing combing with the fans to make system in a cooling status.
• Special technology to prevent interference between each frequency band.
• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.
