High Power Celluar Signal Jammer CDMA GSM 4G 5G WIFI Bluetooth Metal Housing Good Cooling System

Product Details:

Place of Origin:	China
Brand Name:	wolvesteam
Certification:	CE
Model Number:	JM171541

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiated price
Packaging Details:	720(L)×500(W)×330H)mm Box Package
Delivery Time:	3-4 weeks
Payment Terms:	L/C, T/T
Supply Ability:	100pieces/month

Contact Now

Detailed Product Description

Total Output Power:	500W	Operate Time:	24 Hours Continuous
Shielding Radius:	Up To 500 Meter(-75dBm Still Depends On The Signal Strength In Given Area.)	Power Supply:	AC Adapter(AC110V-240V)
Application Area:	Military Units, Prison, Police, Bomb Disposal	Block Frequency:	CDMA GSM DCS PCS 3G 4G 5G WIFI
Power Of Each Frequency Band:	Can Be Adjustable Independently	Feature:	Frequency Bands And Output Power Selectable.
Highlight:	mobile signal jammer , prison cell phone jammers

High Power Celluar Signal Jammer CDMA GSM 4G 5G WIFI Bluetooth Metal Housing Good Cooling System

Product Description:

Portable case RCIED Jammer is a wide-band portable jamming system, designed for the protection of VIP’s and groups of people from radio controlled improvised explosion by disabling the radio exploder control lines in dangerous areas and for the prevention of leakage of information through intercepting units during confidential talks.

Briefcase Jammer transmits RF interference and creates a "Radio Frequency Protected Zone" around the object that prevents remote controlled bomb activation by various RF means in its vicinity with a sufficient jamming safety radius, in order to save lives and prevent serious injuries.

Case Jammers are also deployed to guard forces in the field, Dignitaries and VIP’s, checkpoint and border crossings, roadblocks, Embassies, Police and Government offices etc. Case Jammer is available in various models as per the frequency and output power. However these jammers can be customized as per the user requirements

Specifications

Affected Frequency Ranges:

Output Interface	Shield band of frequency	RF Output Power
CH1 CDMA	850-894MHz	100w
CH2 GSM	925-960MHz	100w
CH3 DCS	1800-1890MHz	100w
CH4 3G	2110-2170MHz	100w
CH5 PCS	1920-1900MHz	100w
CH6 4G lte	(US.725-770MHz) or (EU.800-895MHz)	100w
CH7 4g WIMAX	(US.2345-2400MHz) or (EU.2620-2690MHz)	100w
CH8 5G	3400-3600MHz/3600-3800MHz	100W
Total RF Power	800Watt
Power supply	AC220V
Shielding area	1000-500m @ according to signal density of mobile network
Jammer Module Number	8
Cooling System	Systematic Smart Cooling System
System Protection	VSWR, Over-voltage, Over-current
Jamming Source	PLL Source Technology
Remote Control (Option)	Full System Operation Control
Antenna Type	High Gain Omnidirectional Antennas
Available system:	world wide cell phone network
Power supply:	AC adapter(AC110V-240V)
Operate time:	24 hours continuous
Dimension:	720(L)×500(W)×330H)mm (Not included Antenna)
Weight:	50kg
Air pressure:	86~106kPa
Relative humility:	≤90%(RH)
Temperature :	-40 to +55°C
Directional Antenna:	4pcs antennas ( Please fix the antenna follow the mark in the unit)
Shielding Radius:	Up to 500 meter(-75dBm still depends on the signal strength in given area.)
Operate time:	24 hours continuous
