VVIP Military Protection Vehicle Jammer , 20 - 6000MHz Cell Phone Signal Jammer Device
Product description :
This High Power Full Band Vehicle Military Convoy Protection Roof Mounted Jammer System is a High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.
It is designed for Protect military and country leaders VVIP team,EOD,police investigation and arrestprisons,government buildings, wireless remote bomb and some occasions for a temporary protection to respond to some emergencies.
Features:
1. Equipped with an ultra-broadband frequency bands : 20-6000Mhz
2. All frequency bands are jammed continuously and simultaneously
3. Designed with shockproof case. Easy of mobility.
4. Approved by Military and International Government
5. (Optional) Integrated back-up battery system for continuous silent operation and fast start .
6. Integrated independent "smart active" cooling system .
7. System management (activation, control and operation) is carried out via a remote control unit which is installed (in a covert manner) inside the Driver's console unit.
8. Provided with a on/off switch for each separate frequency band.
9. Special RF protection shielding design to make sure the passenger and VIP's safety .
10. Supplied to the Olympic Event and universiade.
11. To protect military and VIP team as well as some important place from the road-side remote improvised explosive device (RCIED) attacks is becoming a global challenges and tremendous task in security fields.
Advantages and Features
1, Designed with ultra broadband frequency bands, 20MHz-3600MHz (20-6000MHz).
2, 12 modules plug and play design, facilitate for future power upgrading, change and maintenance. Any ruin on the modules never interfere the normal operating of other modules.
3, American Mil-spec standard case, shockproof and drop-resistance, available for the vehicle running in a worse field environment.
4, Up to 20 Frequency Bands. All Jamming Modules Designed by DDS technology.
5, Operators are able to regulate the working frequency band and output power of each module through the software. Configuring a specific frequency band can ensure the internal communication in emergency.
6, System operation can be performed in the driver's console unit. Each module can be ON/OFF. Backup battery or generator system can be optional.
7, Device body is no more than 90kg.
8, Continuously and simultaneously interference to the common used RF signals.
9, Equipped with high power generator to ensure excellent low noise operational capabilities.
10, Integrated backup battery system for continuous silent operation and fast start.
11, Integrated smart active cooling system to make sure the device working continuously.
12, Antenna is installed with a covert design.
13, Video camera with LCD monitor both inside and outside the vehicle provide rear viewing and monitoring
Technical Specifications
11 bands for option: The frequencies can be from 20-6000MHZ
|
Output Interface
|
Frequency Range
|
Out Power |
RF Output dBm
|
|
CH1
|
20-108MHz
|
Wireless ,FM Radio |
100W
|
|
CH2
|
135-174MHz
|
Wilkie-talkie(VHF) |
100W
|
|
CH3
|
300-400MHz
|
Remote Control, Drone |
100W
|
|
CH4
|
400-470MHz
|
Wilkie-talkie(UHF),Car alarm |
100W
|
|
CH5
|
851-894MHz
|
CDMA |
100W
|
|
CH6
|
925-960MHz
|
GSM |
100W
|
| CH7 |
1570-1580MHz |
GPSL1 |
50W |
|
CH8
|
1805-1920MHz
|
DCS,PCS |
100W
|
|
CH9
|
2110-2170MHz
|
WCDMA |
50W
|
|
CH10
|
2400-2485MHz
|
WIFI,Drone,Bluetooth |
50W
|
|
CH11
|
5725-5850MHz
|
WIFI,Drone |
15W
|
|
Jamming Radius:
|
50-800M, the jamming radius still depends on the strength signal in given area
|
|
HS Code:
|
8543709200
|
|
Total output power:
|
600~1200W
|
| Power Consumption: |
330W |
|
Type:
|
Vehicle Jammer
|
|
Dimension:
|
640×540×550 mm
|
|
Packing:
|
Neutral Packing
|
|
Signal Jammer for:
|
20 - 6000MHz Cell Phone Signal Jammer
|
|
Power supply:
|
AC110 240V
|
| Weight: |
75 Kg |
| Humidity: |
5%-95% |
| Working Temp: |
-20℃ to +55℃ |
RF Characteristics:
| RF Characteristics |
Description |
| Output Power |
915 Watts |
| Internal Modulation |
FM Hopping Frequency |
| Signal Source |
VCO Synthesized |
| Power Supply |
AC110-240V,24V or 48V DC |
| Modules Per Unit |
11 |
| Contol |
ON/OFF with Switch |
| Monitoring |
Adjusted output power by DIP switch |
| Antenna |
External- Omni-directional for 360° |
| Power Amplifier Protectors |
Full VSWR Protector |
| Operating Hours |
Unlimited |
Applicable Area:
• Mainly used in examination rooms, prisons, gas stations, mobile phone bombs, oil depots, LPG stations,detention centers, interrogation rooms, courts,
• Reform-through-labour teams, conference rooms, movie theaters, churches, libraries, school dormitories;
• Special security and confidential occasions (confidential office, negotiation room, mobile vehicles, mobile
political and business dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use mobile phones.
Terms and conditions:
|
Delivery Time Schedule
|
Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
|
|
Payment Terms
|
40% advance, 40% after one month,20% before shipping.
|
|
Terms of Delivery
|
FOB HONGKONG/ USA.
|
|
Warranty
|
36 months.
|
|
Software Updates
|
Free software updates will be provided for a period of 36 months.
|
|
Extended Warranty
|
After 4th Year : 5% of total for each years.
|
