Product Description:
High power drone jammer, 300W up to 10000 meters is the latest professional signal jammer of high power. This type of frequencies is especially suitable for drone jammer Built-in high capacity battery and portable backpack design makes this jammer applicable to meeting halls, infantry, military security force, SWAT team, bomb squad, anti-terrorism units, anti-drug units, anti-riot force, the EOD team, checkpoints, hostage negotiations, border control
High RF power, cover 100% drones UAVs Like Dji Phantom 4, Phantom 3 Professional, Advanced, Standard series, Inspire Series... Directional Jamming range: 300~2000 Meters 6-8 Bands in One Device
Specifications
Output Interface RF Frequency Band(MHz) Application RF Output Power (Watt)
CH1 1560-162MHz GPS/GLONASSL1 100W
CH2 2400-2500 MHz WIFI2.4 100W
CH3 5700-5800 MHz WIFI5.8 100W
Total RF Power :300 Watt
Shielding area 8000-10000m @ according to signal density of mobile network
Jammer Module Number 3
Cooling System Systematic Smart Cooling System
System Protection VSWR, Over-voltage, Over-current
Jamming Source PLL Source Technology
Remote Control (Option) Full System Operation Control
Antenna Type High Gain directional Antennas
Number of Antennas 3
Power supply AC110V or AC220V
Power consumption: 1000Watt
Power Supply Source :
Battery ≥ 1 h (at normal capacity)
Battery ≥ 2 h (at full capacity)
Weight: 15.00~18.00Kg
Size (length × wind × high):450×320×80mm box / 550x320x15mm gun
Humidity:30%-95%
Running Temperature: -20 to +55 Celsius Degree
Products Application Fields
High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
Advantages and Features
ABS casing or Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
Heat sink designing combing with the fans to make system in a cooling status.
Special technology to prevent interference between each frequency band.
Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
Frequency bands and output power selectable.
Each frequency band controlled by independent RF ON/OFF switches.
Power of each frequency band can be adjustable independently.
Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
Antenna type options, directional or Omni-directional antennas option.
Easy operation and installation.
Keep for upgrade module installation.
Working 24 hours/365days continuously.
Terms and conditions:
| Delivery Time Schedule |
Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms |
40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc. |
| Terms of Delivery |
FOB HONGKONG/ USA. |
| Warranty |
36 months. |
| Software Updates |
Free software updates will be provided for a period of 36 months. |
| Extended Warranty |
After 4th Year :5% of total for each years. |
