2500MHz IED Vehicle Signal Jammer Radio Controlled

Product Details:

Place of Origin:	China
Brand Name:	Wolvesteam
Certification:	CE
Model Number:	JM311025-4

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiated price
Packaging Details:	Box 520×580×330 mm
Delivery Time:	30 days
Payment Terms:	L/C, T/T
Supply Ability:	100pieces/month

Contact Now

Detailed Product Description

Type:	Waterproof Adjustable	Block Frequency:	20-2500MHz
Total Output Power:	300W	Jamming Range:	Up To 300m, The Jamming Radius Still Depends On The Strength Signal In Given Area
Power Supply:	50 To 60Hz, 100 To 240V AC	Monitor Software Function:	Remote Viewing Each Machine Working State
Advantage:	Each Band Can Adjust RF Power Output Level Or Turn Off Without Influencing The Other Bands’ Operation	Application Area:	Military Units, Prison, Police, Bomb Disposal
Highlight:	IED Vehicle Signal Jammer , 2500MHz Vehicle Signal Jammer , Radio Controlled Adjustable Signal Jammer

Product Description:

Name: 2500MHz IED Vehicle Signal Jammer Radio Controlled
Brand: Wolves Team Limited
SKU: JM311025-4
Price: 1,689.00 USD
Availability: InStock

The High Power IED Jammer shall have the following feature. . Portability.

It shall be lightweight, man portable and comfort to use. . Safety of
Usage. It shall be safe for use. . Simplicity. It shall be simple to set-up
and easy to use. Robustness. It shall be strong and robust to
withstand crush, shock and vibration. Transportability. It shall be
easily transportable by hand, Remote Explosive Ordnance Disposal
Vehicle (REODV) or on any EOD transport vehicle. Maintenance. It
shall be simple to maintain during storage and use. Protection. It
shall be protected from Radio Frequency and Electromagnetic
interference. Reliability. All components shall be highly dependable
to perform its required functions when used in any environment
throughout its shelf life. Environment. It shall be fully tropicalization
and not easily affected by the ingress of moisture or dust.

Advantages and Features:

• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.

• Heat sink designing combing with the fans to make system in a cooling status.
• Special technology to prevent interference between each frequency band.
• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.

Specification

Affected Frequency Ranges: (10bands option)

Output Interface	Output Frequency	Output power
CH1	20-100MHz	50w
CH2	100-500MHz	50w
CH3	500-1000MHz	50w
CH4	1000-1500MHz	50w
CH5	1500-2000MHz	50w
CH6	2000-2500MHz	50w
Total RF Power	300W
Power supply	AC220V
Shielding area	300m @ according to signal density of mobile network
Jammer Module Number	6
Power consumption	1000W
Weight	25.00 Kg
Size (length x wind x high)	320×380×230 mm
Humidity	30%-95%
Running Temperature	-20 to +55 Celsius Degree
Battery Working Time (Option)	2 or 3 hours

Accessories

High Power Cell Phone Signal Jammer
Antennas
Power cable

Products Application Fields

High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
