6 Bands Backpack Signal Jammer GSM 80 Watt Portable Signal Jammer For Army

Brand Name:	wolvesteam
Model Number:	WT600157
MOQ:	1 piece
Price:	negotiated price
Delivery Time:	25 days
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Packing:

Box

HS Code:

8543709200

Jamming Range:

50-150 Meters

Type:

Backpack Jammer

Weight:

25 Kg

Frequency Bands:

6 Bands

Antennae Type:

External High Gain Omni Directional Antenna

Application Area:

Military Units, Prison, Police, Bomb Disposal

Switch Control:

Manually

Output Power:

80 Watt

Packaging Details:

Dimension (not including antennae): 30*45*15cm, Weight:25kg

Supply Ability:

100pieces/month

Highlight:

6 Bands Backpack Signal Jammer

Army GSM Backpack Signal Jammer

80 Watt Portable Signal Jammer

Product Description

6 Bands High Power Backpack Signal Jammer GSM 3G 4G 5G Portable Cell Phone Signal Jammer For Army

Product Description

We have 4-8 bands frequenices optional of this high power cell phone signal jammer.With jamming distance up to 500 meters,this high power GSM CDMA 3G 4GLTE WIFI GPS VHF UHF and Lojack Customized jammer is very competative.
This is a high power efficient jamming device can be used to block unwanted signals in occasions such as VIP convoy protection, military rehearse, municipal hall, police check point, prison, disposal bombs, as well as vehicle mounted to block remote controlled explosive devices.

Features:

Each unit can jam up to 6-8 frequency bands simultaneously.
Continuous operation even in hot climates with no time limits.
Design for portable backpack type.
Secure design to avoid sabotage.
Antenna type Omni antennas,easy setup.
Selection of antennas to provide more flexibility regarding jamming coverage.
Additional option: wireless RC or Ethernet PC remote control.
100% Safe VSWR over protection for each modula.

Specifications:

Output Interface	Output Frequency
CH1	-CDMA: 851-960MHz /-GSM: 925-960MHz
CH2	-DCS: 1805-1880MHz
CH3	-PCS: 192-1990MHz
CH4	-3G: 2110-2170MHz
CH5	-4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU)
CH6	-4G LTE: 725-770MHz(US) or 790-826MHz(EU)
Jammed Signal Freqency:	CDMA,GSM,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF....
Type:	Backpack jammer
Output Channel:	6 output channels
Power Consumption:	Max: 220W
Output power:	80watt
Parameter Shielding Range:	Radius 50-150 meters (-75dBm,depending on the distance of base station in an open filed)
Jammer Module Number	6
HS Code:	8543709200
Packing:	Box
Dimension (not including antennae):	30 45 15cm
Technical Parameters:
Net Weight	12kg
Total Weight	14 kg Aviation Case included
Ambient Temperature	-10ºC - +50ºC
Relative Humidity	≤80%
Power Consumption	≤360W
Power Input	AC100~240V,DC24V
Battery	24V,30AH,Built-in standby battery can used for 90~180 minutes
Antenna Parameters	Omni antennas,gain:4~5dBi
Switch Control	Manually
Equipment Chassis	Metallic Paint
Cooling system	Active "smart" with integrated incoming air filter
Antennae type:	External high gain Omni directional Antenna

We could supply customized service by your detail requirements about frequencies setting. 4-8 Frequency modules we can mix very flexibly.Frequency Ranges Selectable:

CDMA 800:	851-894MHz
GSM 900:	925-960MHz
DCS 1800:	1800-1880MHz
PHS 1900:	1920-1990MHz
3G 2100(UMTS):	2110-2170MHz
WIFI 2.4G Bluetooth:	2400-2500MHz
WiFi3.6G:	3500-3600MHz
Wi-Fi5.2G:	5100-5500MHz
WIFI 5.8G	5725-5850MHz
4G/LTE 700M:	725-770MHz(US)
4G/LTE 800M:	790-826MHz(EU)
4G Wimax:	2300-2400MHz(US)
4G Wimax:	2620-2690MHz(EU)
GPS/L1:	1500-1600MHz
GPS/L2:	1200-1300MHz
GPS/L3:	1300-1400MHz
GPS/L4:	1100-1200MHz
VHF:	135-174MHz
UHF:	400-470MHz
Lojack:	167-175MHz
RF315:	315MHz
RF433:	433MHz
RF868:	868MHz

Application:
Built-in high capacity battery and portable backpack design make this jammer applicable to meeting halls,infantry,military security force,SWAT team,bomb squad,anti-terrorism units,anti-drag units,anti-riot force,the EOD team,checkpoints,hostage negotiations,border control,etc...
Terms and conditions:

Delivery Time Schedule	Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms	40% advance, 40% after one month,20% before shipping.
Terms of Delivery	FOB HONGKONG/ USA.
Warranty	36 months.
Software Updates	Free software updates will be provided for a period of 36 months.
Extended Warranty	After 4th Year :5% of total for each years.
