• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
• Heat sink designing combing with the fans to make system in a cooling status.
• Special technology to prevent interference between each frequency band.
• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.

Specification

• Affected Frequency Ranges:

CH-CDMA/GSM: 850-960MHz
CH-DCS/PCS: 1805-1990MHz
CH-3G: 2110-2170MHz
CH-4G LTE: (USA:725-770MHz) or (Europe:790-826MHz)
CH-4G Wimax: (USA:2345-2400MHz) or (Europe:2620-2690MHz)

CH-5G :3400-3600MHz/3600-3800MHz
CH-WiFi: 2400-2500MHz
CH-GPS: 1500-1600MHz
CH-Lojack: 165-175MHz
CH-VHF: 135-175MHz
CH-UHF: 400-470MHz

• Working Hourslong time:
• Total Power:300W
• Range jamming: 100m to 550m (Depened on signal length)
• Humidity:30%-95%
• Running temperature: -40 to +55 Celsius Degree
• Power supply:AC110-220V Maximum consumption:1500w
• Sidelength × wind × high: 600 × 600 ×800 mm
• Weight: 40 kg

Accessories

• High Power Cell Phone Signal Jammer
• Antennas
• Power cable

Most of us know that in important places like prisons, military meeting and museums, actions have always been taken to prevent the message from being given out. What kind of device can install in these places to reach the purpose, the Rackmount High Power Cell Phone Signal Jammer must be the one which is most suitable.
