4G LTE Vehicle Signal Jammer 500 Meters GSM WIFI GPS 3G 4G 5G

4G LTE Vehicle Signal Jammer 500 Meters GSM WIFI GPS 3G 4G 5G

  • 4G LTE Vehicle Signal Jammer 500 Meters GSM WIFI GPS 3G 4G 5G
  • 4G LTE Vehicle Signal Jammer 500 Meters GSM WIFI GPS 3G 4G 5G
  • 4G LTE Vehicle Signal Jammer 500 Meters GSM WIFI GPS 3G 4G 5G
  • 4G LTE Vehicle Signal Jammer 500 Meters GSM WIFI GPS 3G 4G 5G
4G LTE Vehicle Signal Jammer 500 Meters GSM WIFI GPS 3G 4G 5G
Product Details:
Place of Origin: China
Brand Name: wolvesteam
Certification: CE
Model Number: WT600157-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiated price
Packaging Details: Dimension (not including antennae): 30*45*15cm, Weight:30kg
Delivery Time: 25 days
Payment Terms: L/C, T/T
Supply Ability: 100pieces/month
Contact Now
Detailed Product Description
Packing: Box HS Code: 8543709200
Jamming Range: 50-500 Meters Frequency Bands: 8 Bands
Antennae Type: External High Gain Omni Directional Antenna Application Area: Military Units, Prison, Police, Bomb Disposal
Switch Control: Manually Output Power: 500 Watt
Highlight:

4G LTE Vehicle Signal Jammer

,

Vehicle Signal Jammer 500 Meters

,

GSM WIFI High Power Jammer

VIP Protection High Power Portable GSM WIFI GPS 3G 4G 5G All Cell Phone Signal Vehicle Jammer

Product Description
We have 4-20 bands frequenices optional of this high power cell phone signal jammer.With jamming distance up to 500-1000 meters,this high power GSM CDMA  PCS DCS 3G 4GLTE 4G Wimax 5G WIFI GPS VHF UHF and Lojack Customized jammer is very competative.
This is a high power efficient jamming device can be used to block unwanted signals in occasions such as VIP convoy protection, military rehearse, municipal hall, police check point, prison, disposal bombs, as well as vehicle mounted to block remote controlled explosive devices.
Advantages and Features
1, Designed with ultra broadband frequency bands, 20MHz-3600MHz (20-6000MHz).
2, 12 modules plug and play design, facilitate for future power upgrading,change and maintenance. Any
ruin on the modules never interfere the normal operating of other modules.
3, American Mil-spec standard case, shockproof and drop-resistance, available for the vehicle running in a
worse field environment.
4, Up to 20 Frequency Bands. All Jamming Modules Designed by DDS technology.
5, Operators are able to regulate the working frequency band and output power of each module through the
software. Configuring a specific frequency band can ensure the internal communication in emergency.
6, System operation can be performed in the driver's console unit. Each module can be ON/OFF. Backup
battery or generator system can be optional.
7, Device body is no more than 90kg.
8, Continuously and simultaneously interference to the common used RF signals.
9, Equipped with high power generator to ensure excellent low noise operational capabilities.
10, Integrated backup battery system for continuous silent operation and fast start.
11, Integrated smart active cooling system to make sure the device working continuously.
12, Antenna is installed with a covert design.
13, Video camera with LCD monitor both inside and outside the vehicle provide rear viewing and monitoring

Specifications:

Output Interface Output Frequency
CH1 -CDMA: 851-960MHz /-GSM: 925-960MHz
CH2 -DCS: 1805-1880MHz
CH3 -PCS: 192-1990MHz
CH4 -3G: 2110-2170MHz
CH5 -4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU)
CH6 -4G LTE: 725-770MHz(US) or 790-826MHz(EU)
CH7 -5G:3200-3600MHz
CH8 -5G:3600-4200MHz
CH9 -VHF: 135-175MHz
CH10 -UHF: 400-470MHz
CH11 -WiFi: 2400-2500MHz
CH12 -GPS: 1500-1600MHz
Jammed Signal Freqency: CDMA,GSM,PCS,DCS,3G,4G,5G,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF....
Type: Portable jammer
Output Channel: 12 output channels
Output power: 1000 watt
Parameter Shielding Range: Radius 100-1000 meters (-75dBm,depending on the distance of base station in an open filed)
Jammer Module Number 12
HS Code: 8543709200
Packing: Box
Dimension (not including antennae): 30 *45 *15cm
Technical Parameters:
Net Weight 50kg
Total Weight 55 kg Aviation Case included
Ambient Temperature -10ºC - +50ºC
Relative Humidity ≤80%
Power Consumption ≤360W
Power Input AC100~240V,DC24V
Battery 24V,30AH,Built-in standby battery
can used for 90~180 minutes
Antenna Parameters Omni antennas,gain:4~5dBi
Switch Control Manually
Equipment Chassis Metallic Paint
Cooling system Active "smart" with integrated incoming air filter
Antennae type: External high gain Omni directional Antenna

Application:
• Mainly used in prisons, gas stations, mobile phone bombs, oil depots, LPG stations,detention centers, interrogation rooms, courts,
• Reform-through-labour teams, conference rooms, movie theaters, churches, libraries, school dormitories;
• Special security and confidential occasions (confidential office, negotiation room, mobile vehicles, mobile political and business dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use mobile phones.
Terms and conditions:

Delivery Time Schedule Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms 40% advance, 40% after one month,20% before shipping.
Terms of Delivery FOB HONGKONG/ USA.
Warranty 36 months.
Software Updates Free software updates will be provided for a period of 36 months.
Extended Warranty After 4th Year :5% of total for each years.
