500 Watt Vehicle Signal Jammer DDS Lojack GSM WIFI GPS 500 Meters

Brand Name:	wolvesteam
Model Number:	WT600157-1
MOQ:	1 piece
Price:	negotiated price
Delivery Time:	25 days
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Packing:

Box

HS Code:

8543709200

Jamming Range:

50-500 Meters

Frequency Bands:

8 Bands

Antennae Type:

External High Gain Omni Directional Antenna

Application Area:

Military Units, Prison, Police, Bomb Disposal

Switch Control:

Manually

Output Power:

500 Watt

Packaging Details:

Dimension (not including antennae): 30*45*15cm, Weight:30kg

Supply Ability:

100pieces/month

Highlight:

500 Watt Vehicle Signal Jammer

DDS Lojack Vehicle Signal Jammer

500 Meters Portable Signal Jammer

Product Description

VIP Protection Vehicle Jammer High Power Portable GSM WIFI GPS 3G 4G 5G All Cell Phone Signal Jammer

Product Description
We have 4-20 bands frequenices optional of this high power cell phone signal jammer.With jamming distance up to 500-1000 meters,this high power GSM CDMA PCS DCS 3G 4G LTE 4G Wimax 5G WIFI GPS VHF UHF and Lojack Customized jammer is very competative.
This is a high power efficient jamming device can be used to block unwanted signals in occasions such as VIP convoy protection, military rehearse, municipal hall, police check point, prison, disposal bombs, as well as vehicle mounted to block remote controlled explosive devices.
Advantages and Features
1,Designed with ultra broadband frequency bands, 20MHz-3600MHz (20-6000MHz).
2,12 modules plug and play design, facilitate for future power upgrading,change and maintenance. Any
ruin on the modules never interfere the normal operating of other modules.
3, American Mil-spec standard case, shockproof and drop-resistance, available for the vehicle running in a
worse field environment.
4,Up to 20 Frequency Bands. All Jamming Modules Designed by DDS technology.
5,Operators are able to regulate the working frequency band and output power of each module through the
software. Configuring a specific frequency band can ensure the internal communication in emergency.
6,System operation can be performed in the driver's console unit. Each module can be ON/OFF. Backup
battery or generator system can be optional.
7,Equipped with high power generator to ensure excellent low noise operational capabilities.
8,Integrated backup battery system for continuous silent operation and fast start.
9,Integrated smart active cooling system to make sure the device working continuously.

Specifications:

Output Interface	Output Frequency
CH1	-CDMA: 851-960MHz /-GSM: 925-960MHz
CH2	-DCS: 1805-1880MHz
CH3	-PCS: 192-1990MHz
CH4	-3G: 2110-2170MHz
CH5	-4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU)
CH6	-4G LTE: 725-770MHz(US) or 790-826MHz(EU)
CH7	-5G:3200-3600MHz
CH8	-5G:3600-4200MHz
CH9	-VHF: 135-175MHz
CH10	-UHF: 400-470MHz
CH11	-WiFi: 2400-2500MHz
CH12	-GPS: 1500-1600MHz
Jammed Signal Freqency:	CDMA,GSM,PCS,DCS,3G,4G,5G,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF....
Type:	Portable jammer
Output Channel:	12 output channels
Output power:	1000 watt
Parameter Shielding Range:	Radius 100-1000 meters (-75dBm,depending on the distance of base station in an open filed)
Jammer Module Number	12
HS Code:	8543709200
Packing:	Box
Dimension (not including antennae):	30 45 15cm
Technical Parameters:
Net Weight	50kg
Total Weight	55 kg Aviation Case included
Ambient Temperature	-10ºC - +50ºC
Relative Humidity	≤80%
Power Consumption	≤360W
Power Input	AC100~240V,DC24V
Battery	24V,30AH,Built-in standby battery can used for 90~180 minutes
Antenna Parameters	Omni antennas,gain:4~5dBi
Switch Control	Manually
Equipment Chassis	Metallic Paint
Cooling system	Active "smart" with integrated incoming air filter
Antennae type:	External high gain Omni directional Antenna

Application:
Built-in high capacity battery and portable design make this jammer applicable to meeting halls,infantry,military security force,SWAT team,bomb squad,anti-terrorism units,anti-drag units,anti-riot force,the EOD team,checkpoints,hostage negotiations,border control,etc...
• All kinds of military sites and other prohibited places to use mobile phones.
Terms and conditions:

Delivery Time Schedule	Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms	40% advance, 40% after one month,20% before shipping.
Terms of Delivery	FOB HONGKONG/ USA.
Warranty	36 months.
Software Updates	Free software updates will be provided for a period of 36 months.
Extended Warranty	After 4th Year :5% of total for each years.
