CDMA TDMA UMTS Backpack Signal Jammer GSM 3G 4G 5G 230VAC

At a glance:

• 8 modules are controlled separately and also can work simultaneously.
• Each module with antenna can be used as a single jammer.
• Lightweight Backpack
• Frequency band is optional.
• With excellent heat dispersion.
• Outdoor Waterproof

The Specification for this jammer:

• Output watt: 80watt
• Power Consumption: Max: 380W
• Power supply voltage:~230VAC / ~110VAC
• Power Adjustment: Multi level potentiometer adjustable by computer.
• Battery 2-3 hours
• Range Radius: Up to 150 meters ( signal <=-75dbi in the application place. )
• Housing Metal enclosure
• Total System weight: around 15KG
• Humidity: Up to 80%
• Operation temperatures:-10° … +50° C
• Control Wireless Management Control by Computer
• Cooling system Active “smart” with integrated incoming air filter
• Antennae type External high gain omnidirectional (standard)
• Antenna gain 3-4 dBi (Omni Antenna)
• Omni Antennae number: Omni Antenna Up to 4pcs

Accessories:

• Power adaptor
• Antennas
• User manual

Required Jamming Frequency Bands within 700MHz – 6000MHz Range

Integrated Digital Enhanced Network (iDEN): (807-824)MHz / (852-869)MHz

Global System for Mobile (GSM 900): (880-915)MHz / (925-960)MHz

Satellite Phone System (SPS): (1626.5-1660.5)MHz / (1525-1559)MHz

Global System for Mobile (GSM 1800): (1710-1785)MHz / (1805-1880)MHz

3G Code Division Multiple Access (3G CDMA): (1920-1980)MHz / (2110-2170)MHz

4G Long Term Evolution (4G LTE -FDD): (699-716)MHz / (729 – 746) MHz

4G Long Term Evolution (4G LTE -FDD): (777-798)MHz / (746 – 768) MHz

4G Long Term Evolution (4G LTE -FDD): (703-748)MHz / (758 – 803) MHz

4G Long Term Evolution (4G LTE -TDD): (1880-1930)MHz

4G Long Term Evolution (4G LTE –TDD): (2300 – 2400) MHz

4G Long Term Evolution (4G LTE – TDD): (2496 – 2690) MHz

5G Long Term Evolution (5G LTE – TDD): (3400 – 3800) MHz

5G Long Term Evolution (5G LTE – TDD): (3800 – 4200) MHz

Wireless Fidelity / Wireless Local Area Network (WiFi / WLAN): (2400-2500) MHz
