Adjustable Power Manpack RF Jammer 200 Meters 4G 5G Cell Phone EOD

Brand Name:	wolvesteam
Model Number:	WT600182
MOQ:	1 piece
Price:	negotiated price
Delivery Time:	25 days
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Jamming Range:

50-200 Meters

Type:

Backpack Jammer

Weight:

12 Kg

Frequency Bands:

8 Bands

Antennae Type:

External High Gain Omni Directional Antenna

Application Area:

Military Units, Prison, Police, Bomb Disposal

Output Power:

80 Watt

Frequency Range::

800-4200MHz

Packaging Details:

Dimension (not including antennae): 30*45*15cm, Weight:12kg

Supply Ability:

100pieces/month

Highlight:

Adjustable Power Manpack RF Jammer

200 Meters Manpack RF Jammer

EOD Cell Phone Signal Jammer

Product Description

Adjustble Power EOD Manpack RF Jammer Backpack 4G 5G Cell Phone Signal Jammer

High Power Freqeuncy Scan Convoy Jamming System, implementing the most effective and reliable RF jammer technology and equipped with a fully-integrated broadband jamming system. This is highly portable and light weight.

It plays an important role to use the heavily loaded vehicle and backpack type devices in some extreme hard situation.The operator can carry it forward through the hills and muddy road, as well as Climbing steep mounts and stairs avoid casualties and improve the combat efficiency.

This is full manpack multi band Jamming system is designed with a ruggedized case, light weight, highly mobility and reliance. This device is configured with 8 different jamming modules, the jamming frequency can be more than 8 Bands,the frequency is GSM,CDMS,PCS,DCS,3G,4,5G,5G cell phone signal ,Jamming frequency module can be up to 120 watt output power maximum.

Features:
1. High-power Manpack multi-band RF signal jammer.
2. Modular construction for easy maintenance, repair and upgrade.
3. Jam up to four different jamming modules.
4. Max 120 watt total RF output power.
5. High portable, back pack type.
6. Internal battery, AC mains or DC power.
7. External LCD display to indicate the battery level.
8. Systematic Smart Cooling System.
9. The general design of the system meets military requirements.

Specifications:

Output Interface	Output Frequency
CH1	-CDMA: 851-960MHz /-GSM: 925-960MHz
CH2	-DCS: 1805-1880MHz
CH3	-PCS: 192-1990MHz
CH4	-3G: 2110-2170MHz
CH5	-4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU)
CH6	-4G LTE: 725-770MHz(US) or 790-826MHz(EU)
CH7	-5G:3200-3600MHZ
CH8	-5G: 3600-4200MHZ
Jammed Signal Freqency:	CDMA,GSM,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF....
Type:	Backpack jammer
Output Channel:	8 output channels
Power Consumption:	Max: 220W
Output power:	80watt
Parameter Shielding Range:	Radius 50-200 meters (-75dBm,depending on the distance of base station in an open filed)
Jammer Module Number	8
HS Code:	8543709200
Packing:	Box
Dimension (not including antennae):	30 45 15cm
Net Weight	12kg
Total Weight	12.5kg Aviation Case included
Ambient Temperature	-10ºC - +50ºC
Power Input	AC100~240V,DC24V
Battery	24V,30AH,Built-in standby battery can used for 90~180 minutes
Antenna Parameters	Omni antennas,gain:4~5dBi
Cooling system	Active "smart" with integrated incoming air filter

Application:
Built-in high capacity battery and portable backpack design make this jammer applicable to meeting halls,infantry,military security force,SWAT team,bomb squad,anti-terrorism units,anti-drag units,anti-riot force,the EOD team,checkpoints,hostage negotiations,border control,etc...
Terms and conditions:

Delivery Time Schedule	Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms	40% advance, 40% after one month,20% before shipping.
Terms of Delivery	FOB HONGKONG/ USA.
Warranty	36 months.
Software Updates	Free software updates will be provided for a period of 36 months.
Extended Warranty	After 4th Year :5% of total for each years.
