Name: Software control Bomb IED Military Wireless signal Jammer Shockproof Waterproof Outdoor use 1000 meters
Brand: Wolves Team Limited
SKU: JM166709-a
Price: 1,689.00 USD
Availability: InStock

Home Products Signal Jammer

Software control Bomb IED Military Wireless signal Jammer Shockproof Waterproof Outdoor use 1000 meters

Product Details:

Place of Origin:	China
Brand Name:	wolvesteam
Certification:	CE
Model Number:	JM166709-a

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiated price
Packaging Details:	Box 47 x 11 x 36 cm (Lx W x H)
Delivery Time:	20 days
Payment Terms:	L/C, T/T
Supply Ability:	100pieces/montgh

Contact Now

Detailed Product Description

Output Power:	100W/each Band	Jamming Range:	Up To 1000 Meters Distance
Battery Operation Time:	2-3 Hours	Power Adaptor Input Voltage:	AC220V / DC 28V 190A
Feature:	Special Design With Inner Aluminum Housing	Advantage:	Good Design For Heating Ventilation
Dimension::	625×500×700mm	Antenna Type:	High Gain Omnidirectional Antennas
Frequency:	20-6000MHz	Jamming Source:	Digital Signal Source Technology
System Protection:	VSWR, Over-voltage, Over-current
Highlight:	Outdoor Wireless Signal Jammer , Waterproof Wireless Signal Jammer , Military Wireless Signal Jammer

Software control Bomb IED Military Wireless signal Jammer

Product Description:

This Portable jamming system is designed to effectively jam RCIED threats or RF communications.

The Programmable jamming system is delivered in a flight case trolley configuration complete with antennas,external battery pack,power supply,and remote control .

Specification : DDS Programmable 20-6000MHz

* 850-925 Walky-Talky (UHF800/900) 100w

* 925-960 Cellular GSM900 100w

* 1805-1880 DCS1800 100w

* 1920-1990 PCS1900 100w

* 2110-2170 Cellular UMTS/WCDMA(3G) 100w

* 720-785(US) / 790-826(EU) 4G LTE 100w

* 2300-2400(US) 4G WIMAX 100w

* 2570-2690(EU) 4G WIMAX 100w

* 1570-1580 GPS & Satellite; global star 100w

* 1170-1230 GPS L2/5 100w

* 2400-2500 WIFI & Bluetooth 100w

* 5700-5800 WIFI 5.8G 25w

* 135-175 Walky-talky (VHF) 100w

* 400-480 Walky-talky (UHF400) 100w

* 3400-3600 5G 25w* 3600-3800 5G 25w

* 20-6000MHz Customized Frequencey

We recommend DDS High Power Full Band Portable Military Convoy Protection Roof Mounted Jammer system, It can implement the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.

it can cover, continuously and simultaneously, all the RF communication Frequencies 20MHz~6000MHz (or 20-3600MHz) which are most commonly used by terrorists to detonate road-side bombs (RCIEDs).Adopting the latest jamming technologies, the features ultra-high RF transmission power of 1300 watt, making a bigger shielding range around the vehicle. Beyond the installation of the convoy protection device itself, the vehicle is customized with special RF protection for full protection of the driver and passengers. System management, including activation and control and operation is carried out through a wired remote control unit installed covertly inside the driver’s console unit.

Advantages and Features
Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
Heat sink designing combing with the fans to make system in a cooling status.
Special technology to prevent interference between each frequency band.
Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
Frequency bands and output power selectable.
Each frequency band controlled by independent RF ON/OFF switches.
Power of each frequency band can be adjustable independently.
Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
Antenna type options, directional or Omni-directional antennas option.
Easy operation and installation.
Keep for upgrade module installation.
Working 24 hours/365days continuously.

Main Function
High-power portable multi-band jammer.
Fully modular compact design with extremely high efficient cooling system provides system stability even in extreme climate conditions. The modular design also facilitates easy maintenance, repairs and upgrades.
Jam up to six different jamming modules simultaneously, covering up to 20 different frequency bands.
Increased total RF output power up to 1000 Watts.
Equipped with a wired remote control unit. The operator can ON/OFF each module through the wired remote control.
Fully portable trolley-type case for easy transportation and rapid deployment.
Supplied by AC mains or DC power source.
The jamming system has an active smart cooling system in a continuous working cycle.
Based on our general design, we can further customize our systems for client-specific scenarios both for military and civil applications in order to provide the best individualized solution.
Upgraded jamming signal source (DDS technology) to provide utmost efficiency.(option)
Field programmability for rapid adjustment to frequency and output power. (option)
Software Remote control can control each module working frequency, output power, etc. (option)
