Name: Outdoor Stationary GSM 3G 4G 5G WiFi2.4g CDMA Cellular Signal Jammer Jail Prison Signal Jammer
Brand: Wolves Team Limited
Price: 1,689.00 USD
Availability: InStock

Home Products Outdoor Signal Jammer

Outdoor Stationary GSM 3G 4G 5G WiFi2.4g CDMA Cellular Signal Jammer Jail Prison Signal Jammer

Product Details:

Place of Origin:	China
Brand Name:	Wolvesteam
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiated price
Packaging Details:	Box 550×450×280mm
Delivery Time:	30 days
Payment Terms:	L/C, T/T
Supply Ability:	100pieces/month

Contact Now

Detailed Product Description

Type:	Waterproof Adjustable	Block Frequency:	GSM CDMA 3G 4G 5G WIFI
Total Output Power:	300-750W	Jamming Range:	100- 600m, The Jamming Radius Still Depends On The Strength Signal In Given Area
Power Supply:	50 To 60Hz, 100 To 240V AC	Monitor Software Function:	Remote Viewing Each Machine Working State
Advantage:	Each Band Can Adjust RF Power Output Level Or Turn Off Without Influencing The Other Bands’ Operation	Application Area:	Military Units, Prison, Police, Bomb Disposal
Highlight:	Jail Prison Signal Jammer , 5G WiFi2.4g Signal Jammer , Outdoor Stationary Signal Jammer

High Power GSM 3G 4G 5G WiFi CDMA Cellular Cell Phone Signal Jammer Prison Jammer Waterproof Outdoor Metal Housing

Product Description:

This High Power Full Band Waterproof Outdoor IP65 Convoy Protection Roof Mounted Jammer System is a High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.

Specification

Affected Frequency Ranges:

Output Interface	Output Frequency	Output power
CH1	CDMA/GSM: 850 to 960MHz	50-100w
CH2	DCS : 1805-1880MHz	50-100w
CH3	PCS : 1900-1980MHz	50-100w
CH4	3G : 2110-2170MHz	50-100w
CH5	4G LTE : 725-770MHz(US) or 790-826MHz(EU)	50-100w
CH6	4G Wimax : 2300-2400MHz(US) or 2620-2690MHz(EU)	50-100w
CH7	WiFi: 2400-2500MHz	50-100w
CH8	5G:3400-3600MHz/3600-3800MHz	50-100w

Total RF Power3	400-800W
Power supply	AC220V
Shielding area	100-700m @ according to signal density of mobile network
Jammer Module Number	8
Power consumption	1000W
Weight	38.00 Kg
Size (length x wind x high)	550×450×280mm
Humidity	30%-95%
Running Temperature	-20 to +55 Celsius Degree

Accessories

High Power Cell Phone Signal Jammer
Antennas
Power cable

Most of us know that in important places like prisons, military meeting and museums, actions have always been taken to prevent the message from being given out. What kind of device can install in these places to reach the purpose, the Rackmount High Power Cell Phone Signal Jammer must be the one which is most suitable.

Advantages and Features

Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
Heat sink designing combing with the fans to make system in a cooling status.
Special technology to prevent interference between each frequency band.

Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
Frequency bands and output power selectable.
Each frequency band controlled by independent RF ON/OFF switches.
Power of each frequency band can be adjustable independently.
Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
Antenna type options, directional or Omni-directional antennas option.

Main Function

High-power portable multi-band jammer.
Fully modular compact design with extremely high efficient cooling system provides system stability
even in extreme climate conditions. The modular design also facilitates easy maintenance, repairs and
upgrades.
Jam up to six different jamming modules simultaneously, covering up to 20 different frequency bands.

Equipped with a wired remote control unit. The operator can ON/OFF each module through the wired
remote control.
Supplied by AC mains or DC power source.
The jamming system has an active smart cooling system in a continuous working cycle.
Based on our general design, we can further customize our systems for client-specific scenarios both for
military and civil applications in order to provide the best individualized solution.
Upgraded jamming signal source (DDS technology) to provide utmost efficiency.(option)
Field programmability for rapid adjustment to frequency and output power. (option)
Remote control can control each module working frequency, output power, etc. (option)

Monitor software function: (Option)

Monitoring System Server (option)
Machine Monitor Software Function
Remote control switches of each machine.
Remote adjustment power output of each machine.
Remote viewing each machine working state.
E-mail and Alarming system.
Cabinet opened maliciously Alarming
RF cables cut off deliberately Alarming
Modules failure Alarming
Temperature problem Alarming
Remote viewing offline log of each machine
Mail receiving each machine working state
Set the system permissions function

Technique characteristics:

Taking use of super-high frequency with high effective power.
Effective output power (channel power) and bigger interfere radius.
Only interfere downlink frequency of mobile system,without disturb normally working of Base Stations.
Imported elements: Slow start up design of circuit. These elements can maintain the stable operation condition with high integration.
