Outdoor high power Anti drone jammer system detect and jam range up to 5000 meters

Specification

• Affected Frequency Ranges:

    WiFi 2.4:2400-2485Mhz
    WiFi 2.4:2400-2485Mhz
    WiFi 5.8:5720-5850Mhz
    WiFi 5.8:5720-5850Mhz
    GPS:1560-1625Mhz
   GPS:1170-1250Mhz
   RF900: 820-915MHz
    RF400: 400-470MHz

• The total output power:1000 Watt
• Power supply:110-230AC/DC27V
• Shielding Radius:up to 5000 meters (Depends on the signal strength at the application place.)
• Weight (without antenna): up to 45KG
• Dimension (not including antennae) 36.5*25*48cm
• Cooling system : with integrated incoming air filter
• Housing:Metal enclosure
• Waterproof design
• Antennae type:7dBi high gain omni directional antenna
• Operation temperatures:-10°-+50 C
• Humidity:Up to 80%

Accessories

• High Power Anti drone Jammer
• Antennas
• Power cable

Most of us know that in important places like prisons, military meeting and museums, actions have always been taken to prevent the message from being given out. What kind of device can install in these places to reach the purpose, the Rackmount High Power Cell Phone Signal Jammer must be the one which is most suitable.

Advantages and Features

Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
Heat sink designing combing with the fans to make system in a cooling status.
Special technology to prevent interference between each frequency band.

Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
Frequency bands and output power selectable.
Each frequency band controlled by independent RF ON/OFF switches.
Power of each frequency band can be adjustable independently.
Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
Antenna type options, directional or Omni-directional antennas option.

Main Function

 High-power portable multi-band jammer.
 Fully modular compact design with extremely high efficient cooling system provides system stability
 even in extreme climate conditions. The modular design also facilitates easy maintenance, repairs and
 upgrades.
 Jam up to six different jamming modules simultaneously, covering up to 20 different frequency bands.

 Equipped with a wired remote control unit. The operator can ON/OFF each module through the wired
 remote control.
 Supplied by AC mains or DC power source.
 The jamming system has an active smart cooling system in a continuous working cycle.
 Based on our general design, we can further customize our systems for client-specific scenarios both for
 military and civil applications in order to provide the best individualized solution.
 Upgraded jamming signal source (DDS technology) to provide utmost efficiency.(option)
 Field programmability for rapid adjustment to frequency and output power. (option)
 Remote control can control each module working frequency, output power, etc. (option)
