Military Anti UAV Drone Jammer WIFI GPS RF Control Signal Blocker Portable up to 4500 meters

Military Anti UAV Drone Jammer WIFI GPS RF Control Signal Blocker Portable up to 4500 meters



Product Description:

Drone Jammer Features:

Bulit-in driectional antenna
IR Remote control each band
Frequency bands and output power selectable.
Integrated main equipment, battery, and antennas increases mobility of the device;
Different frequency bands can be controlled independently by different switches;
AC or DC power supply can be selected;
Power Amplifiers protection design ensures the working reliabity of the device.
High performance-price ratio

Drone Jammer Application  Area:

Prevent remote controlled improvised explosive devices from being activated and stop terrorist attacks;

Protect explosives handling experts;

Protect important places such as bus/train stations, plazas, schools, mass gatherings, stadiums, etc;

Risk mitigation and explosives removal in specified spots;

Police used for VVIP convoy, ECM, anti drug, riot control, etc.

Military used for border control, ECM etc.

Drone Jammer Specification:
· Isolating Signal Bandwidth:

CH  WIFI2.4G 2400-2500MHz
CH  WIFI5.8G 5725-5850MHz
CH  GPSL1 1560-1625MHz
CH  GPSL2+L5 1150-1320MHz
CH  RC 900 850-920MHz
CH  RC5.2G 5150-5350MHz
CH  RC 433 310-435MHz
CH  GPSL1-2 1400-1520MHz

Jamming frequency band: GPS,WIFI2.4G, WIFI5.8G
Remote Control: Wire Control Panel Available(optional)
Power supply: 220VAC,24VDC battery ;
Continuous working hours: 24 *7 hours working (AC 220V);
Battery: Built-in lithium Battery, 2 hours by battery, rechargeable;
Wartproof Level:IP65
Antennas type: built-in directional antenna
Main equipment Weight: 8.0kgs;
Dimension:400×180×100mm
Operating Temp: -20ºC - +50ºC
Humidity: 5% - 95%

For medium and long distance applications:

The phased array radar and omnidirectional spectrum sensing equipment are used to form active and passive multi-sensor composite detection for low-speed and small UAV. The photoelectric equipment is equipped with special algorithm to identify and track suspicious targets. After confirming the threat, the fixed intelligent jamming platform can be automatically drive away and forced landing. It can realize the whole process automatic monitoring and control of UAV in the area. It has the characteristics of high detection efficiency, wide coverage and high automation.
