GSM 3G 4G 5G WiFi CDMA Cellular Mobile phone Jammer Waterproof IP65 Outdoor 700 Meters

This prison Jammer  block all the mobile signals as well as other communication signals in the designated places.

Remote software controlled, System architecture should be based on BS + CS mixed
mode, using cloud servers, data should be stored in the cloud, monitor end/serial end can be set in
arbitrary combination a web-based software system. Frequency bands and output power should
have reprogrammable option.

Mobile Phone Jammer Specification

• Applications :

  Border Protection,Anti-terror units, Bomb squads, VIP protection, Convoys protection, Militar y forces, SWAT teams, Polic e forces, Anti-drug units, Riot-control units, Embassies protection, Roadblock protection, Checkpoint protection


  Specification
• Affected Frequency Ranges: Prison Jammer white list black list

• CH-GSM850/CDMA800: 850-894MHz
  CH-GSM900: 925-960MHz
  CH-GSM1800(DCS): 1805-1880MHz
  CH-GSM1900(PCS): 1920-1990MHz
  CH-3G2100(UMTS): 2110-2170MHz
  CH-4G LTE : 725-770MHz(US) or 790-826MHz(EU)
  CH-4G Wimax : 2300-2400MHz(US) or 2620-2690MHz(EU)
  CH-WiFi Bluetooth: 2400-2483MHz
  CH-GPS: 1570-1580MHz
  CH:5G:3400-3600MHz/3600-3800MHz

• Total output power:1000W
• Jamming range: up to 700 meters, the jamming radius still depends on the strength signal in given area
• External double channel directional panel antennas all the TX frequency covered down link only
• Power supply: 50 to 60Hz, 100 to 240V AC
• With AC adapter (AC100-240V-DC27V),
• Dimension: 420×480×130 mm

Jammer Accessories

• High Power Cell Phone Signal Jammer
• Antennas
• Power cable

Most of us know that in important places like prisons, military meeting and museums, actions have always been taken to prevent the message from being given out. What kind of device can install in these places to reach the purpose, the Rackmount High Power Cell Phone Signal Jammer must be the one which is most suitable.

Cellular Jammer Advantages and Features

Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
Heat sink designing combing with the fans to make system in a cooling status.
Special technology to prevent interference between each frequency band.

Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
Frequency bands and output power selectable.
Each frequency band controlled by independent RF ON/OFF switches.
Power of each frequency band can be adjustable independently.
Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
Antenna type options, directional or Omni-directional antennas option.

Main Function

 High-power portable multi-band jammer.
 Fully modular compact design with extremely high efficient cooling system provides system stability
 even in extreme climate conditions. The modular design also facilitates easy maintenance, repairs and
 upgrades.
 Jam up to six different jamming modules simultaneously, covering up to 20 different frequency bands.

 Equipped with a wired remote control unit. The operator can ON/OFF each module through the wired
 remote control.
 Supplied by AC mains or DC power source.
 The jamming system has an active smart cooling system in a continuous working cycle.
 Based on our general design, we can further customize our systems for client-specific scenarios both for
 military and civil applications in order to provide the best individualized solution.
 Upgraded jamming signal source (DDS technology) to provide utmost efficiency.(option)
 Field programmability for rapid adjustment to frequency and output power. (option)
 Remote control can control each module working frequency, output power, etc. (option)
