7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius

7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius

  • 7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius
  • 7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius
  • 7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius
  • 7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius
7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius
Product Details:
Place of Origin: China
Brand Name: Wolves Team
Model Number: WT702807
Contact Now
Detailed Product Description
Weight Of Product: 36.00Kg Feature: Handheld
Jamming Radius: 300-1000m @ According To Signal Density Of Mobile Network Packing: Box
Battery Operation Time: 2-3 Hours With Ac Adapter: AC 230V
Each Frequency Controlled: By Independent RF On/off Switches Frequency Range: GSM,CDMA,DCS,PCS,3G,4G,5G
Highlight:

7 bands portable signal jammer

,

lightweight portable signal jammer

,

300-1000m jamming radius signal jammer

7 Bands Portable Signal Jammer with Lightweight Design 36.00Kg Weight and 300-1000m Jamming Radius
Product Description

This Portable cell phone jammer provides 700W of cell phone jamming power. It is designed for prisons, Omni antenna or detention centers, and penal institutions, etc.

It can greatly reduce the possibility of prison breaks. What's more, it has metal enclosure which prevents sabotage. With the integrated incoming air filter, it ensures the device cooling system operates normally.

This is an optimal choice for you to take this High power 700W portable cell phone jamming system which is specially designed option for Cell Phone, Drone, Walkie-Talkies, GSM, 2G, 3G, 4G LET, 5G and WIFI2.4g 5.8G signals! Besides, you will also be content with the easy operation method and high working efficiency!

Features
  • Aluminum-alloy casing with high protection: The system features an aluminum-alloy casing that offers outstanding resistance against dust, water, and corrosion.
  • Efficient heat dissipation: The heat sink design, coupled with fans, effectively manages the system's temperature.
  • Advanced interference prevention: A specialized technology prevents interference between different frequency bands.
  • Selective frequency interference: Only disrupts the downlink frequency of mobile systems, leaving Base Stations undisturbed.
  • Customizable settings: Users can select frequency bands and adjust output power levels.
  • Individual band control: Each frequency band has independent RF ON/OFF switches.
  • Adjustable power levels: The power output of each frequency band can be adjusted independently.
  • Circuit protection: Includes protection against antenna short-circuiting or disconnection.
  • Antenna versatility: Choice between directional or Omni-directional antenna options.
  • Easy operation and maintenance: Designed for simple operation and installation.
  • Scalable and upgradeable: Supports installation of upgrade modules for future enhancements.
  • Continuous operation: Can operate 24/7 without interruption.
Technical Parameters
Output Interface Output Frequency
CH1 -758-826 GSM850/4G LTE
CH2 -850-960 GSM850/900
CH3 -1805-1880 DCS1800
CH4 -2110-2170 WCDMA(3G)
CH5 -2300-2400 4G WIMAX
CH6 -2550-2690 4G WIMAX
CH7 -3400-3600 5G
Parameter Value
Jammed Signal Frequency CDMA,GSM,PCS,DCS,3G,4G,5G,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF...
Type Portable jammer
Output Channel 7 output channels
Output power 350 watt
Parameter Shielding Range Radius 20-500 meters (-75dBm, depending on the distance of base station in an open field)
Jammer Module Number 7
HS Code 8543709200
Packing Box
Dimension (not including antennae) 30 *45 *15cm
Net Weight 30kg
Total Weight 35 kg Aviation Case included
Ambient Temperature -10ºC - +50ºC
Relative Humidity ≤80%
Power Consumption ≤360W
Power Input AC100~240V,DC24V
Battery 24V,30AH,Built-in standby battery can used for 90~180 minutes
Antenna Parameters Omni antennas,gain:4~5dBi
Switch Control Manually
Equipment Chassis Metallic Paint
Cooling system Active "smart" with integrated incoming air filter
Antennae type External high gain Omni directional Antenna
Applications

High quality jammers are widely used in various fields:

  • Military Units
  • Prisons
  • Police
  • Bomb Disposal
  • Security Services
  • Gas Stations
  • Guard Posts
  • Schools
  • Churches
  • Invigilated Meeting Rooms
  • Libraries
  • Hospitals
  • Theaters
  • Classrooms
  • Other important places and situations
Terms and Conditions
Delivery Time Schedule Delivery time is 2-3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms 50% advance, 50% before shipping.
Terms of Delivery FOB HONGKONG/ USA.
Warranty 36 months.
Software Updates Free software updates will be provided for a period of 36 months.
Extended Warranty After 4th Year :5% of total for each years.
