Product Description:
This High Power Full Band Vehicle Military Convoy Protection Roof Mounted Jammer System is a High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.
It is designed for Protect military and country leaders VIP team, EOD, police investigation and arrest prisons, government buildings, wireless remote bomb and some occasions for a temporary protection to respond to some emergencies.
Also this Bomb jammer can cover, continuously and simultaneously, all the RF communication Frequencies can custom for 20-6000MHz. It will be the best solution to defend a VIP convoy for and features rapid deployment and set up for military bases, important sports events, international summits, and other high profile events.
The Bomb jammer is a fully portable multi-band PLL or DDS Jamming system, and designed with a ruggedized trolley type case for high mobility. This device is configured more than 12 different jamming modules, and the jamming frequency can be more than 12 Bands. This High power Jammer 12 bands jamming frequency modules can provide up to 1200 Watt output power maximum. The Bomb jammer is very easily installed and operated. The device can be powered by AC mains or a suitable DC power source. The general design of the system meets military requirements and international quality standards.
Features:
Aluminum-Alloy Casing
The system features an aluminum-alloy casing with high protection, providing resistance to dust, water, and corrosion.
Cooling System Design
Heat sink design is combined with fans to keep the system in a cooling status, maintaining optimal performance.
Interference Prevention Technology
A special technology is utilized to prevent interference between each frequency band, ensuring consistent and reliable operation.
Selective Frequency Interference
The system only interferes with the downlink frequency of mobile systems, allowing Base Stations to work normally without disruption.
Customizable Features
Frequency bands and output power are selectable, with each band being controlled by independent RF ON/OFF switches. The power of each frequency band can be adjusted independently.
Circuit Protection
Circuit protection is in place to prevent system burnout in case of antenna short circuiting or disconnection.
Antenna Options
Antenna type options include directional or omni-directional antennas, providing flexibility in installation and operation.
Convenient Operation
The system is designed for easy operation and installation, allowing for quick setup and maintenance.
Upgrade Capability
The system is equipped to keep for upgrade module installation, ensuring compatibility with future enhancements.
Continuous Operation
The system is built to work 24 hours a day, 365 days a year, providing reliable performance around the clock.
Technical Parameters:
|
Output
Interface
|
RF Frequency
Band(MHz)
|
Application |
RF Output Power (Watt) |
| CH1 |
20-80 |
Toys HM Remote control |
50W |
| CH2 |
135-175 |
Walky-talky VHF/Lojack |
50W |
| CH3 |
400-480 |
Walky-talky (UHF400) |
50W |
| CH4 |
790-826MHz |
4G/GSM850 |
50W |
| CH5 |
925-960MHz |
GSM900 |
50W |
| CH6 |
1800-1880MHz |
DCS |
50W |
| CH7 |
2100-2170MHz |
3G |
50W |
| CH8 |
2570-2690MHz |
4G WIMAX |
50W |
| CH9 |
3400-3600MHz |
5G |
50W |
| CH10 |
2400-2500 |
WIFI & Bluetooth |
50W |
| CH11 |
5700-5800 MHz |
WIFI 5.8G |
50W |
| CH12 |
1560-1625MHz |
GPSL1 |
50W |
| Option |
20-6000MHz |
Option |
Option |
| Total RF Power |
600Watt |
| Power supply |
Input AC230V |
| Shielding area |
100-300m @ according to signal density of mobile network |
| Jammer Module Number |
12 |
| Cooling System |
Systematic Smart Cooling System |
| System Protection |
VSWR, Over-voltage, Over-current |
| Jamming Source |
PLL Source Technology |
| Remote Control (Option) |
Full System Operation Control |
| Antenna Type |
High Gain Omnidirectional Antennas |
| Number of Antennas |
12 |
| Power consumption: |
600W |
| Power Supply Source (Option) |
Additional AC Alternator ( 600W) or
Additional DC Generator ( +24 VDC/25A ) |
| Weight: |
35.00Kg |
| Size (length × wind × high): |
580×580×680mm |
| Humidity: |
30%-95% |
| Running Temperature: |
-20 to +60 Celsius Degree |
Terms and conditions:
| Delivery Time Schedule |
Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms |
50% advance, 50% before shipping. |
| Terms of Delivery |
FOB HONGKONG/ USA. |
| Warranty |
36 months. |
| Software Updates |
Free software updates will be provided for a period of 36 months. |
| Extended Warranty |
After 4th Year : 5% of total for each years. |
Applications:
High-quality jammers are extensively utilized in various sectors including Military Units, Prisons, Police Departments, Bomb Disposal Units, and Security Services. These devices play a critical role in ensuring security and control over communications in sensitive environments.
In addition to these sectors, they also find application in a range of other settings such as government facilities, Gas Stations, Guard posts, Schools, Churches, Meeting Rooms for invigilation, Libraries, Hospitals, Theaters, Classrooms, and other key locations where stringent control over communication signals is required.
