925W 10 Bands Portable High Power Bomb Cell Phone Signal Jammer WT701808
We recommend DDS High Power Full Band Military Convoy Protection Jammer system, it can implement the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.
It can cover, continuously and simultaneously, all the RF communication Frequencies can be customized to 20~6000MHz (or 20-3600MHz) which are most commonly used by terrorists to detonate road-side bombs (RCIEDs). Adopting the latest jamming technologies, the features ultra-high RF transmission power of 1300 watt, making a bigger shielding range around the vehicle. Beyond the installation of the convoy protection device itself, the vehicle is customized with special RF protection for full protection of the driver and passengers.
System management, including activation and control and operation is carried out through a wired remote control unit installed covertly inside the driver's console unit. Once the system is activated, it transmits unique noise signal which creates "Firewall" between the transmitter (terrorist) and its receiver (explosive device), so can prevent the remote control bomb from the terrorists.
There is absolutely no better way to defend your VIP from the threat of radio-activated bombs.
Features
- High-power portable multi-band jammer.
- Upgraded jamming signal source (DDS technology) to provide utmost efficiency. (option)
- Field programmability for rapid adjustment to frequency and output power.
- Fully modular compact design with extremely high efficient cooling system provides system stability even in extreme climate conditions. The modular design also facilitates easy maintenance, repairs and upgrades.
- Jam up to six different jamming modules simultaneously, covering up to 20 different frequency bands.
- Increased total RF output power can up to 1000Watts.
- Remote control can control each module working frequency, output power, etc.
- Equipped with a wired remote control unit. The operator can ON/OFF each module through the wired remote control.
- Fully portable trolley-type case for easy transportation and rapid deployment.
- Supplied by AC mains or DC power source.
- Backup battery system and generator system are optional.
- The jamming system has an active smart cooling system in a continuous working cycle.
- Based on our general design, we can further customize our systems for client-specific scenarios both for military and civil applications in order to provide the best individualized solution.
Technical Parameters
| Output Interface |
RF Frequency Band(MHz) |
Application |
RF Output Power (Watt) |
| CH1 |
430-450 MHz |
Walky-talky (UHF400) |
100W |
| CH2 |
850-960 Mhz |
Cellular GSM900 |
100W |
| CH3 |
1805-1880 Mhz |
DCS1800 |
100W |
| CH4 |
3400-3600Mhz |
5G |
100W |
| CH5 |
2110-2170 Mhz |
Cellular UMTS/WCDMA(3G) |
100W |
| CH6 |
1800-1880MHz |
DCS |
50W |
| CH7 |
2100-2170MHz |
3G |
50W |
| CH8 |
2570-2690MHz |
4G WIMAX |
50W |
| CH9 |
3400-3600MHz |
5G |
50W |
| CH10 |
2400-2500 |
WIFI & Bluetooth |
50W |
| CH11 |
5700-5800 MHz |
WIFI 5.8G |
50W |
| CH12 |
1560-1625MHz |
GPSL1 |
50W |
| Option |
20-6000MHz |
Option |
Option |
Specifications
Power supply:
Input AC230V
Shielding area:
100-300m @ according to signal density of mobile network
Cooling System:
Systematic Smart Cooling System
System Protection:
VSWR, Over-voltage, Over-current
Jamming Source:
PLL Source Technology
Remote Control (Option):
Full System Operation Control
Antenna Type:
High Gain Omnidirectional Antennas
Power Supply Source (Option):
Additional AC Alternator (600W) or Additional DC Generator (+24 VDC/25A)
Size (length × wind × high):
580×580×680mm
Running Temperature:
-20 to +60 Celsius Degree
Applications
High quality jammers are widely used in Military Units, Prison, Police, Bomb Disposal, and Security Services. They can also be utilized in places such as Prison, Gas Stations, Guard, Schools, Churches, Invigilated Meeting Rooms, Libraries, Hospitals, Theaters, Classrooms, and other important locations and situations.
Question and Answer
1. Does jammer interfere the other electronic equipment to work in normal condition?
No. Because the electromagnetic signal sent by jammer are totally used in the band that regulated by government and just have interception effect to cell phone communication.
2. Is jammer harmful to the human body and cell phone?
Please do not need to worry about it. The intensity of electromagnetic signal sent by jammer is in compliance with the national standard of environmental electromagnetic wave health. The signal sent by jammer is relatively small and unharmful to human body according to the testing result. Meanwhile,this device just damages the receiving condition to the cell phone and makes the normal connection between cell phone and base station impossible. Therefore, no damage will occur on cell phone itself.
3. Is there any difference of distance between using jammer indoor and outdoor?
Yes. Generally speaking, outdoor signal is bigger than the indoor signal. Thereby, the shielding effect is worse outdoor. Strictly speaking, whether using indoor or outdoor, the effective distance of interference is related to the surrounding around, for example the distance between different base stations,positions of installation etc.
Terms and Conditions
| Delivery Time Schedule |
Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms |
50% advance, 50% before shipping. |
| Terms of Delivery |
FOB HONGKONG/ USA. |
| Warranty |
36 months. |
| Software Updates |
Free software updates will be provided for a period of 36 months. |
| Extended Warranty |
After 4th Year : 5% of total for each years. |
