Passive Cooling High Power RF Jammer Module for Continuous Signal Jamming

Brand Name:	Wolves Teams
Model Number:	WT-10W
MOQ:	1
Price:	360
Delivery Time:	15 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,CC

Channels:

Multi-channel Simultaneous Jamming

Modulationtype:

Wideband Noise

Antennas:

8 External Directional Panel Antennas

Operation Temperature:

-20 ...+50 Centigrade Degree

Shielding Radius:

10-40 Meters

Temperature Range:

-20 To +55°C

Product Type:

Desktop/Desktop/Wall Mounted

Jamming Source:

Digital Signal Source Technology

Storage Temperature:

-20℃ ~ +70℃

Jammingdistance:

Up To 100 Meters

Block Frequency:

FM 88-108MHz

Operating Voltage:

AC 110V-220V / DC 24V

Inner Box Dimension:

220×202×65mm

Running Temperature:

-10°C To +55°C

Jamming Radius:

50-150 Meters

Packaging Details:

Carton Packaging

Supply Ability:

Highlight:

Passive Cooling RF Jammer Module

High Power Signal Jammer

Continuous Signal Jamming Module

Product Description

Passive Cooling High Power RF Jammer Module

Professional continuous signal jamming module designed for environments requiring reliable signal control with advanced cooling technology.

Product Overview

This high-power indoor cell phone signal jammer effectively blocks GSM, CDMA, 3G, 4G, 5G, and WiFi 2.4G signals within an 80-meter range. Designed for professional environments requiring signal control, it features advanced cooling systems and continuous operation capabilities.

Key Specifications

Attribute	Value
Output Power	30W / each band
Jamming Range	10-150 meters (signal intensity must < -80dB in location)
Covered Standards	AMPS, N-AMPS, NMT, TACS, GSM, CDMA, TDMA, IDEN, UMTS 4G 5G
Power Supply	Automatic switching 50/60 Hz AC 100-240V to DC 12V
Operating Temperature	-10°C to +60°C
Humidity	95% non-condensing
Antenna	Patch Antenna - Gain 5 dBi of each band
Device Dimensions	38.5cm (L) × 43cm (W) × 26.5cm (H)
Weight	1kg
Storage Temperature	-30°C to +70°C
