7 Bands 350W Brief Case Portable Signal Jammer 30-200M Shielding Range

7 Bands 350W Brief Case Portable Signal Jammer 30-200M Shielding Range

Brand Name:	Wolves Team
Model Number:	808L100-7
MOQ:	1
Price:	1
Delivery Time:	7-15
Payment Terms:	L/C,D/A,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS/FCC/ISO 9000/CE

Product Name:

Portable Trolley Case Full Band Signal Jammer

Model Number:

Customized

Type:

Wireless Signal Blocker

Channel:

7 Channels

Total Power:

350 W

Frequency Band:

2G 3G 4G 5G WiFi GPS Drone Walkie Talkie

Shielding Radius:

50-200m

Protection Level:

IP66 Waterproof Dustproof

Feature:

Portable, Trolley With Wheels, Telescopic Handle

Function:

Signal Blocking, Anti Tracking, Anti Drone, Privacy Protection

Adjustment:

Each Channel Independent Adjustable Power

Heat Dissipation:

Built-in High Speed Cooling Fan

Working Time:

24 Hours Continuous Operation

Customized:

Support Custom Frequency Band

Packaging Details:

Carton Packaging

Highlight:

350W portable signal jammer

7 bands brief case jammer

30-200M shielding range jammer

Product Description

7 Bands 350W Brief Case Portable Signal Jammer

Professional-grade portable signal jammer with 30-200M shielding range designed for security and protection applications.

Key Specifications

Frequency Range	20-6000MHz/700-2600MHz
Frequency	CDMA/GSM/3G Cellphone
Jammer Type	Portable Jammer
Channel Number	7
Each Bands Power	50W
Total Output Power	350W
Jamming Range	2-90m

Product Overview

High power outdoor portable remote-bomb & cell phone WiFi GPS jamming system implementing advanced signal jamming technology. By cutting off data transmission of wireless signals, it provides protection for VIP convoys from threats of Remote Control Improvised Explosive Devices (RCIEDs) and roadside bombs.

Technical Specifications

Output Interface	Shield Band Frequency	RF Output Power	Output Power/Channel
CH1	851-894 MHz	46 dBm	17 dBm/30KHz(min)
CH2	1805-1880 MHz	46 dBm	14 dBm/30KHz(min)
CH3	2110-2170 MHz	46 dBm	15.5 dBm/30KHz(min)
CH4	2100-2170 MHz	46 dBm	15.5 dBm/30KHz(min)
CH5	2300-2400 MHz	46 dBm	15.5 dBm/30KHz(min)
CH6	2400-2500 MHz	46 dBm	15.5 dBm/30KHz(min)
CH7	925-960 MHz	46 dBm	17.5 dBm/30KHz(min)

Physical Specifications

Power Supply	AC110-220V
Shielding Area	30-500M (depending on mobile network signal density)
Power Consumption	200W
Weight	12Kg
Dimensions	390×390×240mm (L×W×H)
Humidity	30%-95%
Operating Temperature	-20 to +55°C

Included Accessories

High Power Cell Phone Signal Jammer
Antennas
Power Cable

Key Features & Advantages

Aluminum-alloy casing with high protection rating, resistant to dust, water, and corrosion
Advanced heat sink design with integrated fans for optimal cooling
Special technology to prevent interference between frequency bands
Only interferes with downlink frequency of mobile systems without disturbing base stations
Selectable frequency bands and output power
Independent RF ON/OFF switches for each frequency band
Independent power adjustment for each frequency band
Circuit protection against antenna short circuiting or disconnection
Optional directional or omni-directional antennas
Easy operation and installation
Upgrade module compatibility
24/7 continuous operation capability

Ordering & Support

Delivery Time	1 month from receipt of confirmed purchase order and advance payment
Payment Terms	40% advance, 40% after one month, 20% before shipping
Delivery Terms	FOB HONGKONG/USA
Warranty	36 months
Software Updates	Free updates for 36 months
Extended Warranty	5% of total cost per year after 4th year

Important Usage Notes

Jamming distances mentioned are for reference only. Actual distance varies based on signal strength, location conditions, and battery charge level.

For portable jammers without cooling fans: Do not use while charging to prevent damage. Usage during charging voids warranty coverage.
