Good price online

products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Signal Jammer
Created with Pixso. 10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security
  • Name
  • Name
  • Name
  • Name
  • Name
  • Name
  • Name

10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security

MOQ: 1
Price: 1
Delivery Time: 7-15
Payment Terms: L/C,D/A,T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ROHS/FCC/ISO 9000/CE
Product Name:
Vehicle Signal Jammer
Product Type:
Vehicle Mounted
Total Output Power:
25W - 3500W
Max Power Per Channel:
10W - 200W
Jamming Radius:
50 - 2000 Meters
Jamming Angle:
90°-360°
Response / Startup Time:
<3 Seconds
Power Supply Method:
DC 12V-28V / DC 24V
Operating Voltage:
12V-24V
Antenna Gain:
≥8 DBi
Operating Temperature:
-40℃ To +65℃
Ingress Protection:
IP65 - IP68
Packaging Details:
Carton Packaging
Supply Ability:
1
Highlight:

10 channel car signal blocker

,

500W waterproof mobile jammer

,

high power signal blocker for security

Product Description
10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security
Product Overview
AC 110-240V 330W Portable Vehicle Cell Phone Signal Jammer GSM Full Band
This high-power phone jammer features independent band control with adjustable power settings. Built with intelligent modules and connection cables, it offers automatic power outage alarm, automatic switching, remote inspection, and comprehensive intelligent digital control without interfering with other devices.
Key Features
  • High-power portable multi-band jammer
  • Field programmability for rapid frequency and power adjustment
  • Modular construction for easy maintenance, repair, and upgrades
  • 250-300 watt total RF output power
  • Remote control unit for individual module ON/OFF operation
  • External LED battery level display
  • External backup battery input for field use
Technical Specifications
Parameter Specification
Frequency Range 20-6000MHz/700-2600MHz
Jammer Type Vehicle Bomb Jammer
Channel Number 10
Total Output Power 330W
Jamming Range 15-100m
HS Code 8543709200
Dimension 640×540×550 mm
Weight 75 Kg
Working Temperature -20℃ to +55℃
Humidity 5%-95%
Frequency Band Details
Output Interface Frequency Range Application Output Power
CH1 20-108MHz Wireless, FM Radio 100W
CH2 135-174MHz Walkie-talkie (VHF) 100W
CH3 300-400MHz Remote Control, Drone 100W
CH4 400-470MHz Walkie-talkie (UHF), Car alarm 100W
CH5 851-894MHz CDMA 100W
CH6 925-960MHz GSM 100W
CH7 1570-1580MHz GPS L1 50W
CH8 1805-1920MHz DCS, PCS 100W
CH9 2110-2170MHz WCDMA 50W
CH10 2400-2485MHz WIFI, Drone, Bluetooth 50W
CH11 5725-5850MHz WIFI, Drone 15W
RF Characteristics
Characteristic Description
Output Power 915 Watts
Internal Modulation FM Hopping Frequency
Signal Source VCO Synthesized
Power Supply AC110-240V, 24V or 48V DC
Modules Per Unit 11
Antenna External Omni-directional for 360°
Operating Hours Unlimited
Applicable Areas
Mainly used in examination rooms, prisons, gas stations, mobile phone bombs, oil depots, LPG stations, detention centers, interrogation rooms, courts, and other prohibited places where mobile phone use is restricted.
Terms & Conditions
Term Details
Delivery Time 3 weeks from receipt of confirmed purchase order and advance payment
Payment Terms 40% advance, 40% after one month, 20% before shipping
Delivery Terms FOB HONGKONG/USA
Warranty 36 months
Software Updates Free updates for 36 months
Extended Warranty 5% of total cost per year after 4th year
Product Images
10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security 0 10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security 1 10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security 2 10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security 3 10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security 4 10 Channels 500W High Power Waterproof Car Signal Blocker for Mobile Security 5
