10 Bands 500W Waterproof Vehicle Signal Jammer Custom Design for Site Security

MOQ: 1
Price: 1
Delivery Time: 7-15
Payment Terms: L/C,D/A,T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ROHS/FCC/ISO 9000/CE
Product Name:
Vehicle Signal Jammer
Product Type:
Vehicle Mounted
Total Output Power:
25W - 3500W
Max Power Per Channel:
10W - 200W
Jamming Radius:
50 - 2000 Meters
Jamming Angle:
90°-360°
Response / Startup Time:
<3 Seconds
Power Supply Method:
DC 12V-28V / DC 24V
Operating Voltage:
12V-24V
Antenna Gain:
≥8 DBi
Operating Temperature:
-40℃ To +65℃
Ingress Protection:
IP65 - IP68
Packaging Details:
Carton Packaging
Supply Ability:
1
Highlight:

500W waterproof signal jammer

,

vehicle signal jammer for security

,

custom site security signal jammer

Product Description
10 Bands 500W Waterproof Vehicle Signal Jammer
Custom designed for comprehensive site security with advanced frequency blocking capabilities
Key Specifications
Frequency Range: 20-6000MHz/700-2600MHz
Jammer Type: Vehicle Bomb Jammer
Channel Number: 10
Each Band Power: 50W
Total Output Power: 330W
Jamming Range: 15-100m
Power Supply: AC 110-240V
Product Overview
This high-power portable vehicle cell phone signal jammer features intelligent modular design with separate band operation capability. Each frequency band can be independently controlled and power-adjusted according to specific security requirements.
Advanced Features
  • High-power portable multi-band jammer with field programmability
  • Modular construction for easy maintenance, repair and upgrades
  • 250-300 watt total RF output power
  • Remote control unit for individual module ON/OFF operation
  • External LED battery level display
  • External backup battery input for field operation
  • Built-in intelligent modules for power outage alarm and automatic switching
  • Comprehensive intelligent digital control without interference to other devices
Technical Specifications
Output Interface Frequency Range Application Output Power
CH1 20-108MHz Wireless, FM Radio 100W
CH2 135-174MHz Walkie-talkie (VHF) 100W
CH3 300-400MHz Remote Control, Drone 100W
CH4 400-470MHz Walkie-talkie (UHF), Car alarm 100W
CH5 851-894MHz CDMA 100W
CH6 925-960MHz GSM 100W
CH7 1570-1580MHz GPS L1 50W
CH8 1805-1920MHz DCS, PCS 100W
CH9 2110-2170MHz WCDMA 50W
CH10 2400-2485MHz WiFi, Drone, Bluetooth 50W
CH11 5725-5850MHz WiFi, Drone 15W
Additional Specifications
Jamming Radius: 50-800M (dependent on signal strength in given area)
Total Output Power: 600-1200W
Power Consumption: 330W
Dimension: 640×540×550 mm
Weight: 75 Kg
Working Temperature: -20℃ to +55℃
Humidity: 5%-95%
RF Characteristics
Parameter Specification
Output Power 915 Watts
Internal Modulation FM Hopping Frequency
Signal Source VCO Synthesized
Power Supply AC110-240V, 24V or 48V DC
Modules Per Unit 11
Control ON/OFF with Switch
Monitoring Adjusted output power by DIP switch
Antenna External Omni-directional for 360° coverage
Power Amplifier Protectors Full VSWR Protector
Operating Hours Unlimited
Applicable Areas
  • Examination rooms and testing centers
  • Prisons and detention facilities
  • Gas stations and oil depots
  • LPG stations and fuel storage areas
  • Detention centers and interrogation rooms
  • Courtrooms and legal proceedings
  • Mobile phone bomb prevention
  • All prohibited areas requiring mobile phone restriction
Product Images
10 Bands 500W Waterproof Vehicle Signal Jammer Custom Design for Site Security 0 10 Bands 500W Waterproof Vehicle Signal Jammer Custom Design for Site Security 1 10 Bands 500W Waterproof Vehicle Signal Jammer Custom Design for Site Security 2 10 Bands 500W Waterproof Vehicle Signal Jammer Custom Design for Site Security 3 10 Bands 500W Waterproof Vehicle Signal Jammer Custom Design for Site Security 4 10 Bands 500W Waterproof Vehicle Signal Jammer Custom Design for Site Security 5
Terms & Conditions
Category Details
Delivery Time 3 weeks from receipt of confirmed purchase order and advance payment
Payment Terms 40% advance, 40% after one month, 20% before shipping
Delivery Terms FOB HONGKONG/USA
Warranty 36 months
Software Updates Free updates provided for 36 months
Extended Warranty 5% of total cost per year after 4th year
