6 Channels 300W High Power Signal Jammer - Block 2G/3G/4G/WiFi/GPS

6 Channels 300W High Power Signal Jammer - Block 2G/3G/4G/WiFi/GPS

Brand Name:	Wolves Team
Model Number:	808L100-10
MOQ:	1
Price:	1
Delivery Time:	7-15
Payment Terms:	L/C,D/A,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ROHS/FCC/ISO 9000/CE

Product Name:

Vehicle Signal Jammer

Product Type:

Vehicle Mounted

Total Output Power:

25W - 3500W

Max Power Per Channel:

10W - 200W

Jamming Radius:

50 - 2000 Meters

Jamming Angle:

90°-360°

Response / Startup Time:

<3 Seconds

Power Supply Method:

DC 12V-28V / DC 24V

Operating Voltage:

12V-24V

Antenna Gain:

≥8 DBi

Operating Temperature:

-40℃ To +65℃

Ingress Protection:

IP65 - IP68

Packaging Details:

Carton Packaging

Supply Ability:

Highlight:

300W high power signal jammer

6 channels portable signal jammer

2G 3G 4G WiFi GPS blocker

Product Description

6 Channels 300W High Power Signal Jammer

Block 2G/3G/4G/WiFi/GPS signals with this professional-grade vehicle-mounted jamming system.

Product Overview

The DDS High Power Full Band Roof Mounted Vehicle Signal Jamming System employs advanced RF jamming technology with a fully integrated broadband jamming solution. This system provides continuous, simultaneous coverage of all mainstream RF communication frequencies from 25MHz to 6000MHz, delivering ultra-high RF transmitting power up to 1300 Watts for maximum shielding effectiveness.

Technical Specifications

Frequency Range	20-6000MHz/700-2600MHz
Frequency Coverage	CDMA/GSM/3G Cellphone
Jammer Type	Portable Jammer
Channel Number	7
Each Bands Power	50W
Total Output Power	500W
Jamming Range	2-90m
Dimension	420×480×130 mm
HS Code	8543709200

High DDS Solution (25-6000MHz)

Output Interface	Output Frequency
CH1	25-500MHz
CH2	500-1000MHz
CH3	1000-2000MHz
CH4	2000-3000MHz
CH5	3000-4000MHz
CH6	4000-5000MHz
CH7	5000-6000MHz

Technical Features

Ultra-high frequency design with high efficient output power
High effective single-channel output power with larger interference coverage radius
Interferes only with downlink frequency of mobile communication systems
Equipped with imported core components and circuit slow-start design
High integration design ensures long-term stable and continuous operation
Prevents interference between each frequency band
Each frequency band controlled by independent RF on/off switches

Key Advantages

Total device weight less than 90kg
Supports continuous and simultaneous interference against commonly used RF signals
Built-in high-power power supply module for excellent low-noise operation
Integrated backup battery system enables fast startup and long-time continuous operation
Intelligent active heat dissipation system for stable long-term performance
Concealed antenna installation for hidden deployment
Internal and external cameras with LCD display for real-time monitoring
Independent adjustment of working frequency bands and output power via control software
In-vehicle control console with individual module ON/OFF switching

Machine Monitoring Software Functions

Remote switch control for each device module
Real-time remote viewing of equipment working status
Remote adjustment of output power for each module
Remote query and viewing of offline operation logs
Automatic email notification of device running status
Multi-level user authority management for system login access

Application Areas

VIP Team, EOD, Government Buildings

Terms & Conditions

Delivery Time Schedule	3 weeks from receipt of confirmed purchase order and advance payment
Payment Terms	40% advance, 40% after one month, 20% before shipping
Terms of Delivery	FOB HONGKONG/USA
Warranty	36 months
Software Updates	Free updates for 36 months
Extended Warranty	5% of total for each year after 4th year

Accessories

Power cable, Antennas, User manual

Manufacturing & Support

With strong R&D groups in the USA and manufacturing facilities in China, we provide a complete range of signal shielding products including Cell Phone, GPS, WiFi, 3G, 4G, LoJack, UHF/VHF, RF, Audio and Wireless Video Signal Blockers, as well as Signal Repeaters, Amplifiers and Signal Boosters. Over 10 years of industry experience ensures reliable and trusted solutions for both personal and commercial applications.
