Indoor Signal Jammer
Created with Pixso. 500W DDS High-Efficiency Fan Cooling Signal Jammer Mobile Phone Signal Inhibitor Indoor Fixed Equipment

500W DDS High-Efficiency Fan Cooling Signal Jammer Mobile Phone Signal Inhibitor Indoor Fixed Equipment

Brand Name: Wolves Team
Model Number: 808H-8
MOQ: 1
Price: 3000
Delivery Time: 7-15 Days
Payment Terms: L/C,D/A,D/P,T/T
Detail Information
Place of Origin:
China
Certification:
CE/ROHS/FCC/ISO9001
Power Supply:
AC 110-220V
Operating Temp:
-20 To +50
Jamming Distance:
Up To 30 Meters
Frequency Jammed:
WiFi / Bluetooth,Wireless Video
Total RF Power:
500~1000W
Weight:
50.00 Kg
Packaging Details:
CartonPackaging
Supply Ability:
1000pcs/month
Product Description
High Power 500W DDS Indoor Signal Jammer Mobile Phone Signal Inhibitor Indoor Fixed Equipment
Product Overview

High Power 500W DDS Indoor Signal Jammer is a professional-grade mobile phone signal inhibitor designed for continuous indoor operation. This fixed equipment provides reliable signal blocking capabilities with advanced features for various applications.

Key Features & Advantages
  • Easy operation and installation
  • Designed for future upgrade module installation
  • Capable of working 24 hours/365 days continuously
  • Aluminum-alloy casing with high protection against dust, water, and corrosion
  • Heat sink design combined with fans for optimal cooling system
  • Special technology to prevent interference between frequency bands
  • Only interferes with downlink frequency of mobile systems without disturbing base stations
  • Selectable frequency bands and output power
  • Each frequency band controlled by independent RF ON/OFF switches
  • Independent power adjustment for each frequency band
  • Circuit protection against antenna short circuiting or disconnection
  • Antenna type options: directional or omni-directional antennas
Technical Specifications
Output Interface Output Frequency Output Power
CH1 CDMA 800: 850 to 894MHz 50-100W
CH2 GSM 900: 925 to 960MHz 50-100W
CH3 GSM 1800: 1805 to 1880MHz (DCS) 50-100W
CH4 GSM 1900: 1920 to 1990MHz (PCS) 50-100W
CH5 3G: 2110 to 2170MHz 50-100W
CH6 4G LTE: (USA:725-770MHz) or (Europe:790-826MHz) 50-100W
Total RF Power 500~1000W
Power Supply AC110/220V
Shielding Area 500-1000m (depending on mobile network signal density)
Jammer Module Number 8
Power Consumption 1000W
Weight 50.00 Kg
Size (L×W×H) 520×580×330 mm
Humidity 30%-95%
Running Temperature -20 to +55 Celsius Degree
Battery Working Time (Option) 2 or 3 hours
Standard Accessories
  • High Power Cell Phone Signal Inhibitor
  • Antennas
  • Power cable
Monitor Software Functions (Optional)
  • Remote control switches for each machine
  • Remote viewing of each machine working state
  • Remote adjustment of power output for each machine
  • Remote viewing of offline log for each machine
  • Email notifications for machine working state
  • System permission settings for login access
Product Gallery
