Military Security 15W 1000M Anti Drone Jammers

Product Details:

Place of Origin:	China
Brand Name:	wolvesteam
Certification:	CE
Model Number:	WT900312

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	negotiated price
Packaging Details:	Size(length × wind × high):960×400×230 mm
Delivery Time:	15 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000pieces/montgh

Contact Now

Detailed Product Description

Size(length × Wind × High):	960×400×230 Mm	Frequency Range:	1.5g 2.4G 5.8g
HS Code:	8543709200	Transport Package:	Neutral Packing
Weight:	6.0Kg	Shielding Area:	500 ~ 1000m
High Light:	1000M Anti Drone Jammers , 15W Anti Drone Jammers

Product Description:

The portable drone jammer is our company's latest product designed by R&D department,the drone jammer disables the targeted drones by remote-control signal and GPS signal, to force the drone fall or return. Effective interference with UAV's Remote-Control Signal 2400MHz, GPS signal 1500MHz,Remote-Control Signal and Image Transmission Signal 5800MHz.

Advantages and Features:

1.Outdoor waterproof case with protection level of IP55

2.UHF broadband jamming technology: highly effective power & long jamming distance

3.Separate control of each module, convenient operation.

4.High quality tubular radiator, effective in radiating heat.

5.High integration components; the moderating circuit-starting design avoids a spark when the device turns on/off. High integration & Stable operation.

6.Batteries are separate from the main device,easy to be replaced and maintained.

Applications:

Mainly applied to prisons, airports, scientific research centers, detention houses,
interrogation rooms, courthouses, labor camp,all kinds of military important places, etc.
that forbid aerial photography by use of UAVs

Technique characteristics:

1.Taking use of super-high frequency with high effective power.

2.Effective output power (channel power) and bigger interfere radius.

3.Only interfere downlink frequency of mobile system,without disturb normally working

of Base Stations.

4.Imported elements: Slow start up design of circuit. These elements can maintain the stable operation condition with high integration.

Specifications:

Output Interface	Shield band of frequency (MHz)	RF Output Power(±1dBm)
CH1	2.4G	40 dBm
CH2	GPS L1	40 dBm
CH3	5.8G	37 dBm
Power supply:	AC110~220V/DC-48V (option)
Total RF Power :	15W
Built-in battery:	DC-24V 8AH/Support 120min Full Power Working (option).
Field strength at -80dBm, Shielding area:	500 ~ 1000m @ according to signal density of mobile network.
Power consumption:	90W
Weight:	6.0Kg
Size(length × wind × high):	960×400×230 mm
Humidity:	30%-95%
Running Temperature:	-10 to +55 Celsius Degree
Packing:	Box

Terms and conditions:

Delivery Time Schedule	Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms	40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc.
Terms of Delivery	FOB HONGKONG/ USA.
Warranty	36 months.
Software Updates	Free software updates will be provided for a period of 36 months.
Extended Warranty	After 4th Year :5% of total for each years.
