| Place of Origin: | China |
| Brand Name: | wolvesteam |
| Certification: | CE |
| Model Number: | WT600152 |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | negotiated price |
| Packaging Details: | Dimension (not including antennae): 30*45*15cm, Weight:25kg |
| Delivery Time: | 25 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100pieces/month |
| Packing: | Box | HS Code: | 8543709200 |
|---|---|---|---|
| Jamming Range: | 50-150 Meters | Type: | Backpack Jammer |
| Weight: | 25 Kg | Frequency Bands: | 6 Bands |
| Antennae Type: | External High Gain Omni Directional Antenna | Application Area: | Military Units, Prison, Police, Bomb Disposal |
| Switch Control: | Manually | Output Power: | 80 Watt |
| High Light: | 80W Electronic Signal Jammer,6 Bands Electronic Signal Jammer |
||
Manpack Phone Signal Blocker Jammer 6 Bands 80W Internal Battery For Police
This is a Cellular RF Wireless Signal jamming system. It designed to block all unauthorized cellular phones and communications devices in prisons and secure facilities, it is an important part of security and crime prevention. The prison Jammer can be easily installed, operating over many frequencies bands cell phones, satellite phone, Wi-Fi and many other communications devices are disabled.
It can be applied that the common used telecommunication frequency will be blocked when the Police arrest the criminals in order to prevent the criminals gang or Police insider leaking the confidence through the wireless equipments ,so that the arrest collapsed. It also make the criminals not be able to remotely control the bomb in the key entrance of the building so that Police can quickly access to the building and round up the criminals to avoid the casualties.
Advantages:
1, Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
2, Heat sink designing combing with the fans to make system in a cooling status.
3,,Special technology to prevent interference between each frequency band.
4,Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
5, Frequency bands and output power selectable.
6,Each frequency band controlled by independent RF ON/OFF switches.
7,Power of each frequency band can be adjustable independently.
8, Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
9, Antenna type options, directional or Omni-directional antennas option.
10,Easy operation and installation.
11, Keep for upgrade module installation.
12,Working 24 hours / 365 days continuously.
Specifications:
| Output Interface | Output Frequency |
| CH1 | -CDMA: 851-960MHz /-GSM: 925-960MHz |
| CH2 | -DCS: 1805-1880MHz |
| CH3 | -PCS: 192-1990MHz |
| CH4 | -3G: 2110-2170MHz |
| CH5 | -4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU) |
| CH6 | -4G LTE: 725-770MHz(US) or 790-826MHz(EU) |
| Jammed Signal Freqency: | CDMA,GSM,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF.... |
| Type: | Backpack jammer |
| Output Channel: | 6 output channels |
| Power Consumption: | Max: 220W |
| Output power: | 80watt |
| Parameter Shielding Range: | Radius 50-150 meters (-75dBm,depending on the distance of base station in an open filed) |
| Jammer Module Number | 6 |
| HS Code: | 8543709200 |
| Packing: | Box |
| Dimension (not including antennae): | 30 *45 *15cm |
| Technical Parameters: | |
| Net Weight | 20kg |
| Total Weight | 25kg Aviation Case included |
| Ambient Temperature | -10ºC - +50ºC |
| Relative Humidity | ≤80% |
| Power Consumption | ≤360W |
| Power Input | AC100~240V,DC24V |
| Battery | 24V,30AH,Built-in standby battery can used for 90~180 minutes |
| Antenna Parameters | Omni antennas,gain:4~5dBi |
| Switch Control | Manually |
| Equipment Chassis | Metallic Paint |
| Cooling system | Active "smart" with integrated incoming air filter |
| Antennae type: | External high gain Omni directional Antenna |
We could supply customized service by your detail requirements about frequencies setting. 4-8
Frequency modules we can mix very flexibly.Frequency Ranges Selectable:
| CDMA 800: | 851-894MHz |
| GSM 900: | 925-960MHz |
| DCS 1800: | 1800-1880MHz |
| PHS 1900: | 1920-1990MHz |
| 3G 2100(UMTS): | 2110-2170MHz |
| WIFI 2.4G Bluetooth: | 2400-2500MHz |
| WiFi3.6G: | 3500-3600MHz |
| Wi-Fi5.2G: | 5100-5500MHz |
| WIFI 5.8G | 5725-5850MHz |
| 4G Wimax: | 2300-2400MHz(US) |
| 4G Wimax: | 2620-2690MHz(EU) |
| GPS/L1: | 1500-1600MHz |
| VHF: | 135-174MHz |
| UHF: | 400-470MHz |
| RF315: | 315MHz |
| RF433: | 433MHz |
| RF868: | 868MHz |
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year :5% of total for each years. |
