| Place of Origin: | China |
| Brand Name: | wolvesteam |
| Certification: | CE |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | negotiated price |
| Packaging Details: | Box 56*45.5*26.5 CM |
| Delivery Time: | 25 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100pieces/month |
| Total Power Output: | 80W 12 -20wat/ Band | Feature: | High Power Radio-frequency Amplifier And Voltage Standing Wave Ratio, Self-protection Of Temperature. |
|---|---|---|---|
| Blocking Range Radius: | Up To 180meters ( Signal Strength <=-75dbm At The Application Place.) | Housing: | Metal Enclosure |
| Antennae Type: | External High Gain Directional (standard) | Application Area: | Military Units, Prison, Police, Bomb Disposal |
| Power Of Each Frequency Band: | Can Be Adjustable Independently | ||
| High Light: | 80W Cell Phone Jammer,80W cell phone signal blocker device |
||
This Portable High Power Wireless Anti-explosion Jammer is the most advanced high efficiency cell phone and satellite signal jammer in the whole world which is professionally designed for bomb disposal and VIP protection like during battle and security safeguard. This certain jammer can block signals in five different frequencies at the same time or separately.
Separate switch for each band, accompanied with a working LED Light.
Simple battery replacement.
Inside cooling fans and heat sink design ensure the device to work continuously. The device surface temperature does not exceed 40 °C after long time working.
Specification:
|
Output Interface
|
Output Frequency | RF Output dBm |
|
CH1
|
PCS/GSM1900 [+PHS] (1930-1990 MHz) | 12-20W |
| CH2 | UMTS (3G) (2110-2170 MHz) | 12-80W |
| CH3 | CDMA/TDMA+Nextel (851-894 MHz), | 12-20W |
| CH4 | IDEN | 12-20W |
| CH5 | AMPS (869-894MHz) | 12-20W |
| CH6 | GSM850 | 12-20W |
| CH7 | GSM (925-960 MHz) | 12-20W |
|
CH8 |
High GSM/DCS (1805-1880 MHz)
|
12-20W |
| Total RF Power | 80Watt, 12 -20wat/ band | |
| Power supply | ~230VAC / ~110VAC | |
| Shielding area | 20-180m @ according to signal density of mobile network | |
| Power Adjustment | 16 levels | |
| Cooling System | Systematic Smart Cooling System | |
| System Protection | VSWR, Over-voltage, Over-current | |
| Housing: | Metal enclosure | |
| Control | Wireless Management Control by Computer | |
| Antenna Type | External high gain directional (standard) | |
| Antenna gain: | 3-4 dBi (Omni directional antenna, no cable ) | |
| Battery Full charge | work time 2hours | |
| Power consumption: | 480W | |
| Weight: | Approx 28kg (with omnidirectional antenna.) | |
| Size (length × wind × high) | 56*46*27 cm | |
| Humidity | Up to 80% | |
| Running Temperature | -20 ...+50 Centigrade degree | |
Optional:
| Computer communication standards 2.4Ghz -WLAN Bluetooth Wi-Fi. |
| Satellite communication systems -Thuraya Iridium Elipso Inmarsat GlobalStar -Aces Odyssey GPS |
| CDMA450 Cellphone System -(430-450/460-470 MHz) |
The accessories of this jammer include:
Products Application Fields
High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 1 or 2 months, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
