| Place of Origin: | China |
| Brand Name: | wolvesteam |
| Certification: | CE |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiated price |
| Packaging Details: | Box , 454x358x160mm |
| Delivery Time: | 20 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100pieces/montgh |
| Output Power: | 120W | Jamming Range: | Up To 100 Meters Distance |
|---|---|---|---|
| Working Hours: | >50000h | Antenna: | Omni-directional Firberglass Antenna |
| Block Frequency: | CDMA GSM DCS 3G 4G 5G WIFI | Application Area: | Military Units, Prison, Police, Bomb Disposal |
| Feature: | Frequency Bands And Output Power Selectable. | Power Of Each Frequency Band: | Can Be Adjustable Independently |
| High Light: | mobile network jammer device,mobile phone network jammer |
||
Application Fields:
High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
Specifications:
Affected Frequency Range:
| Output Interface | Output Frequency | RF Output |
| CH1 | CDMA 869-894MHz | 10-15W |
| CH2 | GSM 930-960MHz | 10-15W |
| CH3 | DCS1805-1880MHz | 10-15W |
| CH4 | 3G 2110-2170MHz | 10-15W |
| CH5 | PCS1930-1990MHz | 10-15W |
| CH6 | 4G LTE: 725-770MHz(US) or 790-826MHz(EU) | 10-15W |
| CH7 |
4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU)
|
10-15W |
| CH8 | 5G:3400-3600MHz/3600-3800MHz | 10-15W |
| Total Output Power: | 80-120 watt | |
| work time | >50000h | |
| Power supply | AC110-230V---DC28V | |
| Shielding area | up to 100m @ according to signal density of mobile network | |
| Jammer Module Number | 8 | |
| Cooling System | Systematic Smart Cooling System | |
| Dimension | 454x358x160mm | |
| Full set weigh | 11.8kg | |
| Remote Control (Option) | Each band can work independently | |
| Working time | Operation 24 hrs / 7 days a week | |
Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
Heat sink designing combing with the fans to make system in a cooling status.
Special technology to prevent interference between each frequency band.
Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
Frequency bands and output power selectable.
Each frequency band controlled by independent RF ON/OFF switches.
Power of each frequency band can be adjustable independently.
Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
Antenna type options, directional or omni-directional antennas option.
Easy operation and installation.
Keep for upgrade module installation.
Working 24 hours/365days continuously.
