| Place of Origin: | China |
| Brand Name: | wolvesteam |
| Certification: | CE |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiated price |
| Packaging Details: | 550 x 400 x 300mm Box Package |
| Delivery Time: | 3-4 weeks |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100pieces/month |
| Total Output Power: | 400W | Jamming Range: | Up To 500m, The Jamming Radius Still Depends On The Strength Signal In Given Area |
|---|---|---|---|
| External Double Channel Directional Panel Antennas: | All The TX Frequency Covered Down Link Only | Power Supply: | 50 To 60Hz, 100 To 240V AC |
| Block Frequency: | CDMA GSM 3G 4G (OPTION) | Dimension: | 588 X 600 X 600mm |
| Feature: | This Device Can Affect Five Different Frequency Ranges At The Same Time | Advantage: | Each Band Can Adjust RF Power Output Level Or Turn Off Without Influencing The Other Bands’ Operation |
| High Light: | mobile network blocker device,mobile phone network jammer |
||
This Selectable Portable High power wireless signal Jammer CDMA/GSM DCS/PCS UMTS/3G 4G 5G All Phone Signal Jammer that you are viewing here is the new designed signal jammer that is designed with the ability to cut off the signals of GSM, DCS, PCS, 3G,4G LTE,4G WIMAX 5G and, i at the same time.
The powerful jammer has a wide affected frequency ranges to include 5G CDMA/GSM, DCS/PCS, 3G, 4G LTE,4G WIMAX . It also has a jamming range up to 500m, depending on the signal strength in the given area. Within the range, just turn on the jammer, all wireless connection to 2G, 3G, 4G 5G network will be disabled at the same time. Also, the jammer is a selectable unit. In other word, user can choose to allow operation of one or a few of frequency bands. Adjustment of ON or OFF any of the single bands will not cause any disruption to the operation of others..
It is especially for military and other large sensitive locations such as military or governmental agencies. It can also be used in Oil and Gas Storage Facilities and fields, Security Services, Military Units, Secret Services, Museums, Border Patrol and Drug Enforcement, Customs, etc.
Specification
Affected Frequency Ranges:
| Output Interface | Output Frequency |
| CH1 | -CDMA 800: 850 to 894MHz |
| CH2 | -GSM 900: 925 to 960MHz |
| CH3 | -GSM 1800: 1805 to 1880MHz |
| CH4 | -GSM 1900: 1920 to 1990MHz (PCS) |
| CH5 | -3G: 2110 to 2170MHz |
| CH6 | -4G LTE (US.725-770MHz) or (Europe:790-826MHz |
| CH7 | -4G Wimax (US.2345-2400MHz) or (Europe.2620-2690MHz) |
| CH8 | -5G :3400-3600MHz/3600-3800MHz |
| Total output power: | 400W |
| Jamming range: | up to 500m, the jamming radius still depends on the strength signal in given area |
| External double channel directional panel antennas | all the TX frequency covered down link only |
| Jammer Module Number | 8 |
| Power supply: | 50 to 60Hz, 100 to 240V AC |
| With AC adapter | (AC100-240V-DC27V) |
| Dimension: | 550 x 400 x 300mm |
Accessories
1. The antennas of the Jamming devices be omni directional
2. The total transmit power of all antennas must be 50 W
3. The Jamming devices, including antennas must be inside the protection box to prevent tampering or entering dust and rain, and proper exhaust fans to maintain the temperature of electronic components
4. The operating temperature of the Jamming device must be between -20°C to +55°C
5. The Jamming device must operate with 100 - 240VAC and 24VDC
6. The total AC / DC power consumption must be less than (100) Watts
7. The Jamming coverage range of the device is from (100 - 300) m in radius
8. The connectivity ports for the Jamming devices are compatible with RJ-45 (TCP / IP and (Loop)).
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
