| Place of Origin: | China |
| Brand Name: | wolvesteam |
| Certification: | CE |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | negotiated price |
| Packaging Details: | Box 36*56*27 cm |
| Delivery Time: | 25 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100pieces/month |
| Total Output Power: | 400 Watt. | Shielding Range:: | 50 To 300m ( Signal Strength <=75dbm.) |
|---|---|---|---|
| Antenna Type: | 8pcs External High Gain ( 3-4dBi ) Omnidirectional ( Standard ) | Feature: | High Power Multi Band |
| Advantage: | Each Band Can Work Independently | Size:: | 36*56*27 Cm |
| Humidity:: | Up To 80% | Operation Temperature:: | -20 ...+50 Centigrade Degree |
| High Light: | 400W Fixed Cell Phone Jammer,CDMA 894MHz Cell Phone Jammer,GSM 3G Outdoor Prison Jammer |
||
At a Glance:
Separate switch for each band, accompanied with a working LED Light.
Simple battery replacement.
Inside cooling fans and heat sink design ensure the device to work continuously. The device surface temperature does not exceed 40 °C after long time working.
Applications:
High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
Specification:
| Output Interface | Output Frequency | RF Output |
| CH1 | CDMA 800: 850 to 894MHz | 50W |
| CH2 | GSM 900: 925 to 960MHz | 50W |
| CH3 | GSM 1800: 1805 to 1880MHz (DCS) | 50W |
| CH4 | 3G: 2110 to 2170MHz | 50W |
| CH5 | 4G LTE: (USA:725-770MHz) or (Europe:790-826MHz) | 50W |
| CH6 | 4G Wimax: (USA:2345-2400MHz) or (Europe:2620-2690MHz) | 50W |
| CH7 | 5G :3200-3600MHz/3600-3800mhZ | 50W |
| CH8 | WIFI2.4g: 2400-2500MHz | 50W |
| Total RF Power | 400Watt | |
| Power supply | AC220V | |
| Shielding area | 50 to 300m ( signal strength <=75dbm.) | |
| Jammer Module Number | 8 | |
| Antenna Type | 8pcs External high gain ( 3-4dBi ) omnidirectional ( Standard ) | |
| Weight | 40.00 Kg | |
| Size (length x wind x high) | 36*56*27 cm | |
| Humidity | 30%-95% | |
| Running Temperature | -20 to +55 Celsius Degree | |
Accessories:
Advantages and Features
· Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
· Heat sink designing combing with the fans to make system in a cooling status.
· Special technology to prevent interference between each frequency band.
· Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
· Frequency bands and output power selectable.
· Each frequency band controlled by independent RF ON/OFF switches.
· Power of each frequency band can be adjustable independently.
· Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
· Antenna type options, directional or omni-directional antennas option.
· Easy operation and installation.
· Keep for upgrade module installation.
· Working 24 hours/365days continuously.
